Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Inconel 601 Wire UNS N06601 2.4851 Alloy Wire 0.03mm - 10mm For Industrial Furnance
Specifications
Brand Name :
OHMALLOY
Model Number :
601
Certification :
ISO ROHS
Place of Origin :
China(Shanghai)
MOQ :
20kg
Price :
negotiable
Payment Terms :
, L/C, T/T
Supply Ability :
20000T/Year
Packaging Details :
IN SPOOL DIN 250
Delivery Time :
7-20days after your deposit received
Powder Or Not: :
No
Surface :
Bright
Werkstoff Nr. :
2.4851
UNS :
N06601
Type :
Ni-Cr-Fe Alloy
Craft :
Cold Drawing
Description

Inconel601 wire , UNS N06601 2.4851 Alloy wire(0.03mm~10mm) popular for Industrial furnance

1.Description

It is face-centered cubic lattice structure for use at temperature up to 1370°C (2500°F).The Nickel-Chromium alloy is characterized by excellent inoxidability in the high temperature and sulfur atmosphere,good resistance to carbonizing.It has high creep rupture strength since it limits the carbon content and grain size, so recommend to use for above 500°C environment.

Inconel 601

Chemical Content(%)

Alloy % Ni Cr Fe C Mn Si Cu Al P S

Inconel

601

 Min. 58 21 1.0
Max. 63 25 Bal. 0.1 1.5 0.5 1.0 1.7 0.02 0.015

Mechanical Properties

Aolly status Tensile strength
Rm N/mm²		 Yield strength
R P 0.2N/mm²		 Elongation
A 5 %		 Brinell hardness
HB		 Density
g/cm³

Melting Point

°C
Annealing
treatment		 650 300 30 - 8.1 1320-1370
Annealing
treatment		 600 240 30 ≤220 8.1 1320-1370

2.Features

Excellent inoxidability in the high temperature(the temperature can be up to 1180°C),good resistance to carbonizing,good inoxidabilitiy in sulfur atmosphere,good mechanical property,good resistance to stress corrosion cracking and high spalling resistance.

3.Usage

It is widely used in following field:

1)Petrochemical processing:separate tank of ammonia reforming and catalytic support grid of nitric acid producing.

2)Industrial furnaces:steel shares at annealing and radiation control, high-speed gas burners, Industrial furnace silk.

3)Gas turbine components:exhaust system parts,solid waste incinerator's combustion chamber,channel support and soot dealing parts,detoxification exhaust system components.
4)Heat treating equipment:the tray,basket and tool clamp in the heat treatment factory,oxygen re-heater.

4.Grade Contrast

ASTM(American Society for Testing and Materials):UNS N06601

DIN(Deutsche Industrie Normen):W.Nr.2.4851,NiCr23Fe
