HTHP Low Consumption Fabric Dyeing Machine Adjustable 420r/Min Fabric Speed
HTHP Low Consumption Fabric Dyeing Machine Adjustable 420r/Min Fabric Speed
HTHP Low Consumption Fabric Dyeing Machine Adjustable 420r/Min Fabric Speed
HTHP Low Consumption Fabric Dyeing Machine Adjustable 420r/Min Fabric Speed
HTHP Low Consumption Fabric Dyeing Machine Adjustable 420r/Min Fabric Speed
HTHP Low Consumption Fabric Dyeing Machine Adjustable 420r/Min Fabric Speed
Specifications
Brand Name :
Alees
Model Number :
AS Win
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD5000-250000
Supply Ability :
50 sets per month
Delivery Time :
6-9 weeks
Packaging Details :
Wooden Case/Plastic Film
Shape :
O Shape
Material :
SUS 316L
Voltage :
380V-50HZ 220V-50HZ 440V-50HZ
Controller :
SETEX797 / AS12(China) / SEDOMAT 6007 / EAS-PCT310
Control System :
Full Automatic
Nozzle Size :
110/140/168
Description

Introduction


AS-Win series redefines high-temperature fabric dyeing with its industry-leading ultra-low liquor ratio capabilities, achieving 1:4.5 for 100% cotton and 1:3.5 for synthetic fibers. Engineered for versatile performance, this system efficiently processes natural fibers, cotton blends, viscose hybrids, and elastic mixed-spun textiles across a broad temperature range. Its advanced hydrodynamic design ensures thorough color penetration while maintaining fabric integrity under demanding thermal conditions. AS-Win equipped with adjustable fabric block plate, uniform dyeing liquid distribution system, adjustable nozzle, intelligent fabric seam detector and fabric storage tank with teflon tube.


Technical Parameters


-Maximum fabric speed: 420r/min

-Maximum working pressure: 0.4Mpa

-Maximum operating temperature: 135℃
-Heating rate: 20℃~100℃ average 5℃/min

100℃~130℃ average 2.5℃/min
(dry saturated steam pressure at 0.7Mpa)
-Cooling rate: 130℃~60℃ average 2.5℃/min
(cooling water pressure at 0.3Mpa, cooling water temperature: 5℃~10℃)

-Liquor Ratio: 1:4



Model and Specifications


Model

Capacity (KG)

Dimension

Main Pump Power (KW)

L*W*H (MM)

AS-Win-MINI-25KG

25

2780*2020*3000

7.5

AS-Win-MINI-50KG

50

2980*3670*3200

7.5

AS-Win-MINI-100KG

100

3000*370083400

7.5

AS-Win-1T

250/270

4100*5600*4300

7.5

AS-Win-2T

500/540

5300*5500*4300

15

AS-Win-3T

750/810

6500*6200*4300

22

AS-Win-4T

1000/1080

8300*6500*4300

30

AS-Win-5T

1250/1350

9650*6400*4300

37

AS-Win-6T

1500/1620

10500*6500*4300

45

AS-Win-8T

1875/2000

12100*6500*4300

55

Controller
