BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant
BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant
BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant
BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant
BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant
BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant
Specifications
Eyewash Bowl :
Stainless Steel
Shower Head Type :
Deluge
Material :
Stainless Steel
Mounting Type :
Recessed
Emergency Shower Flow :
120-180L/min
Drain :
1-1/4
Eyewash Bowl Material :
ABS Plastic
Valve Type :
Stay-Open Ball Valve
Country Of Origin :
China
Compliancepen Ball Valve :
ANSI Z358.1.2014（OSHA）
Compliance :
ANSI Z358.1.2014（OSHA）
Bowl :
Stainless Steel Bowl
Flow Rate :
20 GPM
Activation Method :
Pull Handle
Activation :
Pull Handle
Price :
¥1500
Description
  1. Product Name: Large Pedal Automatic Drain Combined Eyewash
  2. Brand: Bohua
  3. Model: BH30-5012
  4. Production Standards: GBT38144.1/2-2019, US ANSI Z358.1-2014.
  5. Function: Eyewash + Shower + Automatic Drain.
  6. Nominal Pressure: 1.0 MPa.
  7. Operating Pressure: 0.2-0.4 MPa.
  8. Eyewash Flow Rate: ≥11.4 L/min.
  9. Shower Flow Rate: ≥76 L/min.
  10. Inlet Size: 1-1/4" Internal Thread, 102mm Height
  11. Outlet Size: 1-1/4" Internal Thread, 102mm Height
  12. Gross Weight: 19 kg
  13. Net Weight: 17 kg
  14. Medium: Domestic water at room temperature that meets hygienic standards.
  15. Main Material: 304 stainless steel
  16. Eyewash nozzle: Fixed soft rubber dust cover prevents loss, and the soft rubber design prevents eye injuries. A built-in multi-layer filter effectively filters impurities from the water, creating a foamy flow.
  17. This product is suitable for use in winter environments with temperatures as low as -5°C and includes an automatic drain function for antifreeze protection.
  18. Suitable for use in a wide range of industries and sectors, including nuclear power, power plants, pharmaceuticals, medical treatment, chemicals, petroleum, shipbuilding, electronics, smelting, printing and dyeing, education, and scientific research.


BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant


BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant


BH30-5012 Stainless Steel Pedal Eyewash Station ANSI Z358.1 Compliant
