Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel
Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel
Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel
Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel
Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel
Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel
Specifications
Flow Rate :
20 GPM
Spray Head :
Dual Spray Heads
Valve Material :
Brass
Valve Type :
Ball Valve
Eyewash Spray Type :
Soft Flow
Emergency Shower Flow :
120-180L/min
Compliance :
ANSI Z358.1.2014（OSHA）
Eyewash Activation :
Push Handle
Eyewash Bowl :
Stainless Steel
Material :
Stainless Steel
Compliancepen Ball Valve :
ANSI Z358.1.2014（OSHA）
Type :
Wall Mounted
Eyewash Flow Rate :
1.5 GPM
Activation :
Push Handle
Activation Method :
Pull Handle
Price :
¥1500
Description
  1. Product Name: Vertical Eyewash (Enhanced Anti-corrosion)
  2. Brand: Bohua
  3. Model: BH32-1011
  4. Production Standards: GBT38144.1/2-2019, US ANSI Z358.1-2014.
  5. Function: Eyewash.
  6. Nominal Pressure: 1.0 MPa.
  7. Operating Pressure: 0.2-0.4 MPa.
  8. Eyewash Flow Rate: ≥11.4 L/min.
  9. Inlet Size: 1-1/4" Internal Thread, 814mm Height.
  10. Outlet Size: 1-1/4" Internal Thread, 135mm Height.
  11. Gross Weight: 7 kg.
  12. Net Weight: 6 kg.
  13. Medium: Domestic water at room temperature that meets hygienic standards.
  14. Main Material: 304 stainless steel with ABS anti-corrosion coating.
  15. Eyewash Nozzle: Fixed soft rubber dust cover, prevents loss, and the soft rubber design prevents eye injuries. The built-in multi-layer filter effectively filters impurities from the water, creating a foamy flow.
  16. This product is suitable for use in environments with temperatures above 0°C.
  17. Applicable Applications: Widely used in nuclear power, power plants, pharmaceuticals, medical treatment, chemicals, petroleum, shipbuilding, electronics, smelting, printing and dyeing, education, and scientific research units, industries, and fields.


Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel


Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel


Bohua BH32-1011 Anti-Corrosion Vertical Eyewash Station 304 Stainless Steel
