Specifications
Brand Name :
MEPER
Model Number :
MP80FD
Place of Origin :
China
Certification :
CE/ISO9001:2008
MOQ :
1set
Price :
Price negotiation.
Packaging Details :
Standard export package
Delivery Time :
25-35 work days
Payment Terms :
L/C, T/T
Supply Ability :
100 sets per month
Blow Molding Type :
Extrusion Blow Molding Machine
Contactor :
Schneider
Applicable Material :
HDPE LDPE PP
Warranty Time :
1 Year
Product :
Milk Bottle Packing Bottle
Blow Moulding Type :
Extrusion Blow Moulding
Clamping System :
Toggle Type Clamping System
Color :
Customized
Description

Product Description:

One of the standout features of this machine is its 4 cavity design, which allows for multiple products to be manufactured simultaneously, thus increasing productivity and efficiency. Additionally, the machine is equipped with a toggle-type clamping system that ensures precise and consistent clamping force, resulting in consistent product quality.
The Automatic Blow Moulding Machine also comes with a Schneider contactor, which is known for its reliability and durability. This component ensures that the machine operates smoothly and efficiently, with minimal downtime due to maintenance or repairs.
This plastic blow moulding machine is suitable for a wide range of applications, including the production of milk bottle packing bottles. Its efficient and reliable performance makes it an excellent choice for manufacturers looking to streamline their production process and increase their output.
When it comes to durability and reliability, the Automatic Blow Moulding Machine delivers. It comes with a 1-year warranty, giving you peace of mind and assurance that your investment is protected. Whether you're looking for a 5 gallon blow molding machine or a plastic blow moulding machine for other applications, this machine is a great choice that will deliver consistent results.

Features:

  • Product Name: Automatic Blow Moulding Machine
  • Clamping System: Toggle Type Clamping System
  • Operation: Automatic
  • Contactor: Schneider
  • Blow Molding Type: Extrusion Blow Molding Machine
  • Color: Customized

This custom blow molding machine is perfect for creating PET bottles with an automatic extrusion blow molding machine. The toggle type clamping system and reliable Schneider contactor make it a top choice for industrial use.

Technical Parameters:

PARAMETERS MP80FD φ80
SPECIFICATIONS
material PE
MAX container capacity L 10
number of die Set 1,2
machine dimension(L×W×H) M 3.4×5.6×2.36
total weight Ton 14
CLAMPING
clamping force KN 150
platen opening strokes mm 240-640
toggle stroke mm 400
Max mould size(W×H) mm 580×470
EXTRUDER UNIT
screw diameter mm 80
screw L/D ratio L/D 24
(HDPE)plasticizing capacity kg/h 100
screw heating zone zone 4
screw heating power kw 15.85
fan power kw 0.28
extruder driving power kw 30
DIE HEAD
die head heating zone zone 3
power of die heating kw 10
ENERGY-CONSUMPTION
power of the electric motor kw 29
air pressure Mpa 0.6-0.8
total power of machine kw 85.13
average energy consumption kw 42
compression air consumption m3/min 1.2
cooling water consumption L/minv 80



Applications:

One of the key features of the MEPER MP75AE is its toggle type clamping system. This system provides a high level of stability and precision, ensuring that the machine can produce high-quality products consistently. The machine is also equipped with a powerful Schneider contactor, which further enhances its reliability and performance.
The MEPER MP75AE is capable of producing products using a range of materials, including HDPE, LDPE, and PP. It has 4 cavities, which makes it ideal for producing large quantities of products quickly and efficiently. This makes it an excellent choice for businesses that need to produce a high volume of products in a short amount of time.
Some of the application occasions and scenarios for the MEPER MP75AE Automatic Blow Moulding Machine include:

  • Manufacturing: The machine is perfect for businesses that need to manufacture a wide range of products, such as plastic bottles, containers, and other plastic products.
  • Packaging: The machine can be used to produce custom blow molding products for a range of different packaging needs, including food packaging, cosmetics packaging, and more.
  • Automotive: The machine can also be used in the automotive industry to produce a range of different products, such as fuel tanks, oil tanks, and more.
  • Medical: The machine can be used to produce medical products, such as medicine bottles, syringes, and other medical equipment.

The MEPER MP75AE Automatic Blow Moulding Machine is capable of producing high-quality products quickly and efficiently. With a supply ability of 100 sets per month and a delivery time of 25-35 work days, this machine is a great investment for any business that needs a reliable and high-performing blow molding machine. Contact us today to learn more about this product and to place your order.
