Specifications
Brand Name :
QingDao Zhenxiong
Model Number :
SJHJ
Certification :
CE certification
Place of Origin :
Qingdao,China
MOQ :
1 set
Price :
6000 - 6500USD per set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
15 - 25 working days
Packaging Details :
After being wrapped with stretch film , it is shipped unpacked in the container .
Weight :
360 kg
Dimension :
1840 * 1300 * 1220 mm
Features :
can weld dual angles at once
Note :
Different models and configurations are available for customization
Description
Door Gasket Production Line Auto Gasket Welding Machine
Simultaneous Dual-Angle Welding Solution
Key Attributes
  • Weight: 360 kg
  • Dimensions: 1840 × 1300 × 1220 mm
  • Core Feature: Simultaneous dual-angle welding capability
  • Note: Customizable models and configurations available
Product Overview

This fully automatic double-angle welding machine specializes in 90° sealing strip welding. Utilizing advanced programmable control technology, it delivers exceptional welding precision and efficiency with its unique dual-angle welding capability, significantly boosting production output.

Core Advantages
  • PLC automatic control system ensures stable operation, high precision, and consistent welding quality
  • Dual-hole automatic welding with integrated weld bead cleaning reduces labor requirements
  • Patented upper/lower layer mold design enables simultaneous dual-angle welding, doubling production capacity
  • Comprehensive safety features including photoelectric protection, dual-hand start buttons, and cut-off switches
  • High production capacity of 600-650 sets per shift
  • Premium components: PLC controls, SXPC pneumatic systems, and branded electrical components
  • Exceptional weld strength withstands high pressure without deformation
  • Consistently produces flat, firm, and aesthetically perfect weld corners
Applications

Ideal for high-volume production of door seals for refrigerators, freezers, disinfection cabinets, water dispensers, and similar applications. Features automatic weld bead removal for streamlined operation.

Technical Specifications
Model ZXHJJ
Overall Dimensions 1840 × 1300 × 1220 mm
Horizontal Clamping Stroke 50mm
Vertical Clamping Stroke 98mm
Work Efficiency 600-650 sets/shift
Motor Power 2.1kw
Electro Heating System Power 1.95kw
Weight 360kg
Product Images
Door Gasket Production Line Auto Gasket Welding Machine Weld Two Corners At Once Door Gasket Production Line Auto Gasket Welding Machine Weld Two Corners At Once Door Gasket Production Line Auto Gasket Welding Machine Weld Two Corners At Once Door Gasket Production Line Auto Gasket Welding Machine Weld Two Corners At Once Door Gasket Production Line Auto Gasket Welding Machine Weld Two Corners At Once Door Gasket Production Line Auto Gasket Welding Machine Weld Two Corners At Once Door Gasket Production Line Auto Gasket Welding Machine Weld Two Corners At Once
Note: Different models and configurations are available for customization to meet specific production requirements.
