Specifications
Brand Name :
QingDao Zhenxiong
Model Number :
SJ120
Certification :
ISO9001
Place of Origin :
Qingdao,China
MOQ :
1 set
Price :
220000 - 300000 USD per set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
15 - 25 working days
Packaging Details :
After being wrapped with stretch film , it is shipped unpacked in the container .
Dimensions :
50000 * 2000 * 2800 mm
Motor power :
250KW
Production capacity :
700 - 900 Kg / h
Weight :
10 tons
Description
ISO9001 HDPE PVC Extruder Machine 50000MM Polyethylene Pipe Production Line
Product Specifications
Dimensions 50000 × 2000 × 2800 mm
Motor power 250KW
Production capacity 700 - 900 Kg/h
Weight 10 tons
Product Overview

HDPE Large Diameter Plastic Pipe Machine Intelligent Operation High Pipe Quality

Our HDPE large-diameter pipe equipment can produce two-layer, three-layer, multi-layer composite pipes or reinforced composite pipes by replacing the pipe mold, increasing the number of single-screw extruders, and updating the production line.

Core Advantages
  • Professional single screw host with optimized variable pitch double line wavy design and strong cold reverse feeding section ensures high production while maintaining material stability and reducing energy consumption
  • Spiral splitter head mold ensures even flow distribution, uniform pipe wall thickness, and smooth inner/outer walls
  • Advanced PLC control system enables full line synchronization and automation with intelligent human-machine interface
  • Dual waterway system allows filter replacement without stopping production and achieves high-speed shaping/cooling
  • Rubber block crawler traction with variable frequency speed regulation provides wide adjustment range and smoother production
  • Fully automatic chipless cutting mechanism with hydraulic feed system ensures clean, smooth cutting surfaces
  • Produced pipes feature smooth surfaces, strong pressure resistance, corrosion resistance, aging resistance, and impact resistance
Production Line Models
Pipe Specifications (mm) Extruder Output (kg/h) Available Sizes
160-315 90×33 350-450 160,180,200,225,250,280,315
315-630 120×33 850-1000 315,355,400,450,500,560,630
710-1200 90×33 120×33 1200-1500 710,800,900,1000,1200
Applications
  • Urban water supply and drainage systems (main pipes and branch pipes)
  • Old city pipe network renovation projects
  • Industrial raw material transportation for chemical, food, paper, and other industries
  • Industrial wastewater and sewage discharge systems
  • Transportation of minerals, coal ash, and river sediment
  • Agricultural irrigation systems
