Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
Specifications
Brand Name :
QingDao Zhenxiong
Model Number :
SJ120
Certification :
ISO9001
Place of Origin :
Qingdao,China
MOQ :
1 set
Price :
220000 - 300000 USD per set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
15 - 25 working days
Packaging Details :
After being wrapped with stretch film , it is shipped unpacked in the container .
Warranty :
12 months
Single Screw :
SJ120 Single Screw
Dimensions :
50 * 2 * 2.8 m
Weight :
Weight approximately 10 tons
Description
Single Screw 50m Plastic Pipe Machine Smoothing HDPE Pipe Making Machine
Product Specifications
Warranty 12 months
Single Screw SJ120 Single Screw
Dimensions 50 × 2 × 2.8 m
Weight Approximately 10 tons
HDPE Large Diameter Plastic Pipe Machine

Our HDPE large-diameter pipe equipment can produce two-layer, three-layer, multi-layer composite pipes or reinforced composite pipes by replacing the pipe mold, increasing the number of single-screw extruders, and updating the production line.

Core Advantages
  • High-efficiency design: Features a specialized single-screw main engine with optimized screw design for stable material plasticization while reducing energy consumption.
  • Precision engineering: Spiral diversion die head mold ensures uniform wall thickness and smooth inner/outer pipe surfaces.
  • Advanced control: PLC system enables full-line synchronization and automation with intuitive operation interface.
  • Continuous operation: Dual waterway system allows filter replacement without stopping production.
  • Optimized traction: Rubber block crawler system with variable frequency speed adjustment for smoother production.
  • Precision cutting: Fully automatic chipless cutting mechanism with hydraulic feed system for clean cuts.
  • Superior output: Produces pipes with excellent pressure resistance, corrosion resistance, and impact resistance.
  • Custom solutions: Equipment tailored to your specific production needs and facility layout for optimal integration.
Pipe Production Line Specifications
Pipe Specifications (mm) Extruder Output (kg/h) Available Sizes
160-315 90×33 350-450 160,180,200,225,250,280,315
315-630 120×33 850-1000 315,355,400,450,500,560,630
710-1200 90×33 120×33 1200-1500 710,800,900,1000,1200
Application Scope
  • Urban water supply and drainage systems (main pipes and branches)
  • Pipe network reconstruction in urban areas
  • Industrial applications: chemical, food, paper, and textile processing
  • Industrial wastewater and sewage discharge systems
  • Transportation of minerals, coal ash, and river mud
  • Agricultural irrigation systems
Product Images
Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine Single Screw 50m Plastic Pipe Machine Smoothing Hdpe Pipe Making Machine
