Specifications
Brand Name :
Qingdao Zhenxiong
Model Number :
SJ90
Certification :
ISO9001
Place of Origin :
Qingdao,China
MOQ :
1 set
Price :
50000 - 80000 USD per set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
15 - 25 working days
Packaging Details :
After being wrapped with stretch film , it is shipped unpacked in the container .
Note :
Different models and configurations are available for customization
PLC control :
Yes
Description
Large Diameter Plastic Pipe Machine with Smooth Wall Finish
High Output, Low Cost Winding Solution
Note: Different models and configurations are available for customization
Core Advantages
  • Equipped with two single screw extruders for square tube and rubber extrusion with special screw design for high yield and low temperature plasticizing
  • Composite head with double machine joint feeding and spiral rotation forming ensures superior product quality
  • Advanced PLC control system with high precision temperature control for stable operation
  • Multi-axis transmission structure provides large power transmission with stable operation and long service life
  • Available in multiple size ranges: 300-1200mm, 800-1600mm, and 1600-3000mm inner diameter options
  • Produces pipes with smooth inner/outer walls featuring high ring stiffness, light weight, pressure resistance, corrosion resistance, and long lifespan
Applications

Ideal for municipal renovation projects, construction, industrial/agricultural drainage, water-saving irrigation, and sewage treatment systems. Features low assembly cost, easy operation, and economical connection methods for wide market potential.

Technical Specifications
Model SJ-90
Production Capacity 200Kg/h
Screw Diameter 90mm
Max Extrusion Diameter 90mm
Pipe Diameter Range 300-1200mm
Overall Dimensions 30000 × 4000 × 5000mm
Motor Power 55kw
Weight 3-5 tons
Control System PLC
