Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Specifications
Brand Name :
Qingdao Zhenxiong
Model Number :
SJ90
Certification :
ISO9001
Place of Origin :
Qingdao,China
MOQ :
1 set
Price :
50000 - 80000 USD per set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
15 - 25 working days
Packaging Details :
After being wrapped with stretch film , it is shipped unpacked in the container .
weight :
3 - 5 T
Productive capacity :
200Kg/h
specification :
300 - 1200mm
Note :
Different models and configurations are available for customization
Description
Plastic Automated Pipe Machine 300MM - 3000mm Hollow Wall Winding Pipe Machine
Weight 3 - 5 T
Productive capacity 200Kg/h
Specification 300 - 1200mm
Note Different models and configurations are available for customization
Automated Plastic Pipe Machine PLC Control 300 - 3000mm Hollow Wall Winding Pipe

Engineered for quality, high-speed operation, and maximum efficiency in extrusion processes. Scientifically designed for low production costs and high output.

Core Advantages
  • Equipped with two single-screw extruders for square tube and rubber extrusion, featuring special screw design and feeding system for high-yield extrusion and low-temperature plasticization
  • Composite head design with dual-machine joint feeding, spiral rotation molding, and high-efficiency composite process ensures superior product quality
  • Advanced PLC control system with high-precision temperature control module for stable operation and accurate control
  • Multi-axis transmission structure in spiral forming machine provides large transmission force, stable operation, and extended service life
  • Multiple size options available: 300-1200mm, 800-1600mm, and 1600-3000mm models
  • Produces hollow wall winding pipes with smooth surfaces, high ring stiffness, lightweight construction, pressure resistance, toughness, corrosion resistance, and long service life
Application Scope

Widely used in municipal renovation projects, construction, industrial/agricultural drainage, water-saving irrigation, and sewage treatment. Features low assembly cost, easy operation, simple connection, and significant cost savings with excellent market potential.

Model SJ-90 Production Capacity 200Kg/h
Screw Diameter 90mm Overall Dimensions 30000 × 4000 × 5000mm
Max. Extrusion Diameter 90mm Motor Power 55kw
Pipe Diameter Range 300-1200mm Weight 3 - 5 tons
