Specifications
Brand Name :
Kechengda
Model Number :
SJ-65/28
Place of Origin :
Shandong, China
MOQ :
1
Price :
USD 17000~36000
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
35 work days
Packaging Details :
wrapping film
Screw Design :
Single-screw
Screw L/D Ratio :
28:1
Condition :
New
Plastic Processed :
PVC
Application :
Profile
Showroom Location :
Canada, Italy, France, Germany, Viet Nam, Philippines, Saudi Arabia, Indonesia, Mexico, Russia, Spain, Thailand, Kenya, South Korea, Chile, UAE, Colombia, Algeria, Romania, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Japan
Weight :
15000 KG
Warranty :
1 Year
Key Selling Points :
Automatic
Applicable Industries :
Building Material Shops, Manufacturing Plant, Construction works
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox, Screw
Machinery Test Report :
Provided
Screw Material :
38CrMoALA
Screw diameter (mm) :
45
Screw Speed (rpm) :
80 rpm
Voltage :
Customized
Dimension(L*W*H) :
Customized
Power (kW) :
11
Extruder Speed Adjusting Way :
Frequency Conversion
Extruder model :
SNJ45/28
Extruder power(KW) :
11KW
Capacity(kg) :
20
Rotating speed of screw :
80r/min
Raw materials :
PVC
Usage :
Sealing Strip
Description

Introduction of PVC profile production line:

1. Supply PVC rubber refrigerator door and window sealing strip production line equipment PE silicone PVC seal production and processing equipment manufacturers supply PE luggage strip extruder, luggage molding equipment, luggage cartoon production line luggage plastic line production equipment, luggage production equipment, luggage plastic cartilage production line Equipment, luggage plastic parts, molybdenum production equipment, plastic molding machine, production equipment, luggage edge of the strip equipment, luggage embedded equipment, the supply of PVC silicone PVC seal production and processing equipment.
2. The PVC profile extrusion line is equipped with conical single-screw extruder. The production line has many advantages: material thawing even, small shear rate, high output, long service life, etc. The production line includes extruder, calibrator unit, haul-off unit, double station winder or stacking unit, etc.
Application:
It is used for producing pvc sealing strip, the sealing strip is widely use in window and door profile, car industry. It is composed of feeding system,extruder,water cooling system,haul-off unit,winding machine or double roller,electric control system and coordinated with different specification of moulds.This line is advanced in design,high in output,good in plasticization and low in energy consumption.The finished product is widely used in cars, windows, refrigerators, etc.

Processing Flow:
Raw material → Single-screw extruder →Extrusion mould →Vacuum calibration table → Haul-off unit→ Automatic cutter→ Stacker →Finished product inspecting & packing

Features :
- PLC control system is available
- All electrical components adopts famous brand : OMRON, ABB, SIEMENS etc
- Over current protective of motor
- With online protection film wrapping device
Main Technical Parameter
SJ45/28 Single Screw Extruder
Screw diameter
45mm
L/D
28:1
Motor Power
11Kw
Rotating speed of screw
80r/min
Heating Power
8Kw
Extrusion Capacity
20 Kg/H
Center Height
1000mm
Weight
800Kg
Dimension
2050*1200*1500mm
Extruder Speed Adjusting Way
Frequency Conversion
Barrel Temperature Adjusting Way
Heating: Cast Aluminum Heater

Production process

On-line hot stamping process
Raw material mixing→ Screw feeder → Extruder → Mould → Vacuum forming table→Hot stamping machine →Haul-off machine→ Cutting machine → Stacker(finished product)
Off-line transfer laminating process
Raw material mixing→ Screw feeder → Extruder → Mould → Vacuum forming table→Haul-off machine→ Cutting machine → Transfer table→Lamination machine → Stacker(finished product)
Waste plastic:Crushing machine→Milling machine
Details
1
Screw feeder
2
YF series conical twin screw extruder
3
Extrusion Mould
4
vacuum forming table
5
haul off
6
auto cutting machine
7
stacker
Supporting machine(optional)
1
High speed mixing machine
2
Hot stamping machine(or Laminating machine)
3
Crushing machine
4
Milling machine
