Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Long Life PLC WPC PVC Furniture Foam Sheet Plate Extrusion Production Line, Waterproof PVC Cabinet Board Machine
Specifications
Brand Name :
Kechengda
Model Number :
SJSZ-80/156
Place of Origin :
Qingdao,Shandong,China
MOQ :
1
Price :
USD 94000~150000
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
35 work days
Packaging Details :
wrapping film
Screw Design :
Double-screw
Screw L/D Ratio :
22:1
Condition :
New
Plastic Processed :
PVC, Stone vinyl
Application :
Sheet, Plates
Weight :
26000 KG
Warranty :
1 Year
Key Selling Points :
Turn-key project service
Applicable Industries :
Building Material Shops, Manufacturing Plant, Restaurant, Food Shop, Printing Shops
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, Pump, Gear, PLC, Gearbox, Screw
Machinery Test Report :
Provided
Screw Material :
38CrMoALA
Screw diameter (mm) :
92/188
Screw Speed (rpm) :
35 rpm
Voltage :
380
Dimension(L*W*H) :
25m*5m*5m
Power (kW) :
200
Name :
pvc cabinet board machine
Inverter :
Siemens top G120 series
calibration :
mature device for many years
advantage of line :
stable, longevity, high efficiency
calender :
double work positions 4/6 rollers
output thickness :
3-30mm
output width :
970mm or 1220mm
Keywords :
anti-scratch decorative pvc sheet
After-sales Service Provided :
Video technical support
After Warranty Service :
Spare parts
Description

Output dimension of PVC cabinet board machine

Extruder Mold SYSJ-80/156 SYSJ-80/173 SYSJ-92/188 SYP-114 SYP-135
Output capacity kgs/h 350 550 650 650 1200
Output thickness mm 3-25 3-30 3-30 3-30 3-40

List of machines and advantages

NO. Name of machine Advantage of machine
1 Automatic feed loader Fully automatic
2 Conical Twin Screw extruder Inverted SIEMENS motor, famous brand gearbox and full set of SIEMENS electric control system,30% ENERGY SAVING, STABLE RUNNING, LONG SERVICE LIFE
3 T-die Design by ourself with over 15 years manufacturing experience
4 Calibrator 100mm thickness mirror surface calibrator
5 Cooling Bracket 9 pcs stainless iron rollers
6 Haul off machine 8-12 pairs rubber surface rollers
7 Transverse cutter
8 Stacker
Auxiliary machines(optional)
1 Crusher For recycling unqualified board
2 Grinder For recycling unqualified board
3 High-speed Heat/Cooling Mixer For mixing raw materials
4 Chiller To supply cool water
