Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Plastic PVC Cover Ceiling Panel Making Machine PVC Sheet Production Line
Specifications
Brand Name :
Kechengda
Model Number :
SJSZ-65/132
Place of Origin :
Qingdao,Shandong,China
MOQ :
1
Price :
usd 30000~80000
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
35 work days
Packaging Details :
wrapping film
Screw Design :
Double-screw
Screw L/D Ratio :
30:1
Condition :
New
Plastic Processed :
PVC
Application :
Profile
Weight :
7000 KG
Warranty :
1 Year
Key Selling Points :
High Productivity
Applicable Industries :
Hotels, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Food Shop, Construction works , Food & Beverage Shops, Advertising Company
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Pressure vessel
Machinery Test Report :
Provided
Screw Material :
38CrMoAlA
Screw diameter (mm) :
120
Screw Speed (rpm :
36rpm
Voltage :
220-460V
Dimension(L*W*H) :
23x2x2m
Power (kW) :
60
After-sales Service Provided :
Online support
Capacity/output :
80-300kg/hour
raw material :
PVC, Caco3, Stabilizer, CPE------
Further processing :
hot stamping, printing, laminating
Description

Plastic PVC Cover Ceiling Panel Making Machine PVC Profile/Wall Panel Production Line/Extruder Machines

General description

1.The equipment adapts to various formulations, the ratio of calcium can be increased up to 50%-250%, while the required accessories can be reduced by 30%

2.The ceiling the extruder products has an exquisite appearance and uniform plasticization
3. Laser tracking eliminates problems regarding the extrusion flow rate, which helps achieve automation of the entire extrusion process

4 The PVC ceiling extrusion machine has auto-alarm functions in case of emergency, through the use of PID controller

Which is mainly used in the area of PVC ceiling, integrated ceiling, luggage
board, ceiling corner etc. the equipment consists of conical twin-screw extruder
vacuum shaping table, tractor, cutter and stacker, It has high-techlaser tracking
device exclusive, to ensure not only extrude PVC ceilings with high quality and
output also greatly reduce the cost of production, which get appreciations from
customers

Machine details

Model SJSZ48(50) SJSZ55 SJSZ65
Main power(kw) 15 22 37
Product width(mm) 300 200-600 300-600
Total Power(kw) 34 47 66
Output capacity(kg/h) 110-160 120-190 150-210
Length of line 18.5 20 21.5
Air compression(mpa/m3) 0.5 0.6 0.6
