300W Intelligent LED Street Light for Street Road Park Square Lighting
300W Intelligent LED Street Light for Street Road Park Square Lighting
300W Intelligent LED Street Light for Street Road Park Square Lighting
300W Intelligent LED Street Light for Street Road Park Square Lighting
300W Intelligent LED Street Light for Street Road Park Square Lighting
300W Intelligent LED Street Light for Street Road Park Square Lighting
Specifications
Brand Name :
E-lite
Model Number :
EDGE Street Light
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
L/C, D/A, D/P, T/T, PAYPAL
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
Pretection Degree :
IP66 / Ik10
MOQ :
1pcs
Delivery :
DHL/UPS/AIR
Time :
5-7 days
HS Code :
9405409000
Work temp :
-35ºC~+50ºC
Description

300W Intelligent LED Street Light for Street Road Park Square Lighting

Competitive advantages:


1. Module design, power can be 50W - 240W;
2. Supply ETL DLC CE, EMC, TUV, ROHS, WEEE, IP66, IK09, 10KV, IES and so on. High quality, able to meet the bidding requirements of most markets. Detailed operating manuals were produced.
3. Performance driver and cable are well-known brands to make sure premium quality. More than 60% of the workers are skilled workers of 4-5 years, and the performance of the products is stable.
4. Good sealing and heat dissipation performance, IP66 waterproof, dustproof. The working temperature can be more than 50,000 hours without working temperature from -35 °C to +50 °C.

5. Applicable to - parking lights outdoor parking lights, LED stadium lights, area lights, street lights, shoe box lights, farms, playgrounds, tennis courts, garden parks, gas station roads, street and road area lighting.

Specifications
Model EO-ST-50 EO-ST-100 EO-ST-150 EO-ST-200 EO-ST-240
LED Brand LUXEON® 3030 2D
Driver Brand Inventronics Driver
Norminal Wattage 50W 100W 150W 200W 240W
LED Quantity 56 pcs 112pcs 168pcs 224pcs 280pcs
Input Voltage 100-240/277VAC
Power Efficiency >90%
Power Factor >0.95
Luminous Efficiency >130lm/w
Lamp Rated Lumen output 7000lm 14000lm 21000lm 28000lm 33600lm
Color Rendering Index Ra>70
Color Temperature 3000K,4000K,5000K,5700K
Photometric Type Type I Medium;Type II Medium;Type III Medium,TypeV,Short
Optimal Operating Temperature 25°
Storage Temperatures -40°C~50°C
Working Environment Between-40°C~+50°C, 10%~90%RH
Total Harmonic Distortion < 10%
Lumen Maintenance > 100000 hours -L70, @25 ºC (77 ºF)
Wind Index Force 12
Body and Shell Materials Anodized Aluminum
IP Rating IP66 with test report
IK Rating IK10with test report
Certification CE,ROHS,ENEC,GS,CB,UL,cUL,DLC,LM-79,LM-80
Optional Function 1-10V
Photocell Control
Warranty 5 years
Packing Details
Fixture Dimension 592x386 x83 678x380x83 774x380x83 868x380x83 960x380x83
Fixture Weight 5.9 kg 7.0kg 8.0kg 9.1kg 10.3kg

300W Intelligent LED Street Light for Street Road Park Square Lighting

300W Intelligent LED Street Light for Street Road Park Square Lighting

300W Intelligent LED Street Light for Street Road Park Square Lighting

Outdoor LED street light 24-hour aging test:


Before shipment, all LED street lamps will be tested for aging more than 24 hours. The inspection department will test 100% of the products, including lighting test, power test, high voltage test, waterproof test, grounding test, etc. The defect rate is controlled. Less than 0.1%. Quality is guaranteed, you can rest assured.

FAQ:

1. Q: Are you a factory or a trading company?

A: We are a manufacturer with a 3KW plasma cutting machine, 3000W and 2000W laser cutting machines, 350T and 1000T stretcher machines to make sure our producing capability.Welcome OEM and ODM for you.

2. Can we have a sample order?

A: Of course! Any sample order is welcome for testing and checking.

3. What is the warranty for the products?

A: Battery:3 years. Controller/LED:5 years. Pole/solar panels:15-20 years

4. How to ship the goods?

A: By sea usually. If urgent requirement, air-shipping is available(except:Batteries)

5. How to deal with the fault?

A: If the problem caused by manufacturing quality, we will change and replace it in free.

Save Money:

Low and stable voltage power consumsion for the solar street lamp, no maintenance costs - Saving maintenance costs

Save on electricity bills: Street light use polycrystalline silicon photovoltaic panels with the high photoelectric conversion efficiency, no electricity costs are incurred.

Easy installation, wire connection is no need, which we can massivefully save manpower consumsion and finacial resources.
