Specifications
Brand Name :
E-lite
Model Number :
Grapheneism™ UFO High Bay
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
L/C, D/A, D/P, T/T, PAYPAL
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
LED Chip :
Lumileds
Color Temperature :
4500~5500K (Standard) 2500~5500K (Optional)
CRI :
≥70
Lumen Maintenance :
L70>90,000 hours TM-21 Calculated
Input Voltage :
347/480V
Power Factor :
0.95 minimum
IP Rating :
IP66 & IP69K
Description

ETL UFO LED High Bay Light / Industrial Lighting 200W With 0-10V Dimmable

PRODUCT FEATURES:

  • System light efficacy 140 LPW
  • 40% lighter in weight compared to regular LED high bay,easy installation /maintenance.
  • Superior electrical and thermal conductivity.
  • Much stronger and durable than steel,suitable for all tough environment.
  • Tilted heat sink back design for easy wash-off.
  • Eco friendly and recyclable.
  • 5 Years warranty

TYPICAL APPLICATIONS

  1. Warehouse/Manufacturing Facilities
  2. Convention Centers/Sporting Arenas
  3. Big-Box Retail Stores
  4. Cold Storage Facilities
  5. Gymnasiums

Parameter:

Wattage 240W 200W 150W 100W
Input Voltage AC 347/480V 50/60Hz
LED Driver E-Lite / Sosen / MW
LED Chip Lumileds / CREE
Power Factor ≥0.95
Efficacy 140 lm/W
Luminous Flux 33,600 lm 28,000 lm 21,000 lm 14,000 lm
CRI ≥70
Lumen Maintenance L70>120,000 Hrs
Colour Temperature 4500~5500K (2500~5500K Optional)
Beam Angle 90° Ribbed Lens
120° Ribbed Lens
120° Clear Flat Lens
120° Diffused Dome Lens
120° Clear Dome Lens
90° Reflector
100° Reflector
IP Rating IP65 & IP69K
Operating Temperature -30 to 45°C (-22 to 113°F)
Dimensions 325x325x183mm 325x325x183mm 320x320x159mm 280x280x162mm
Net Weight 5.6 kg 5.3 kg 3.5 kg 2.9 kg
Certification ETL DLC CB GS TUV CE ROHS SAA
Warranty 5 years
Material Graphene Composite Hear Sink

COMPLIANCE & APPROVALS:

· American market: ETL, DLC Premium

· European market: TUV, GS, CB, CE, RoHS, WEEE

· Australian market: SAA

· LM-79 Reports / LM-80 Reports / TM-21 Data / IES

347V UFO LED High Bay Light / Industrial Lighting 200W With 0-10V Dimmable ETL

347V UFO LED High Bay Light / Industrial Lighting 200W With 0-10V Dimmable ETL


http://www.exteriorled-lighting.comhttps://www.elitesemicon.com/file/upload/file/20190304/E-Lite%20Grapheneism%20High%20Bay%20Series%202019(18035784).pdf
