Specifications
Model NO. :
M3-010200-D2
Carrying Capacity :
Special Weight Level
Moves :
Stationary
Driven Type :
Hydraulic
Running Mode :
Stationary
Certification :
CE, ISO 9001
Product Name :
2600mm Hydraulic Scissor Lift Working Platform
Capacity :
1000kg
Lift Stroke :
2000mm
Close Height :
600mm
Transport Package :
Wooden Pallet
Trademark :
Marco
Origin :
Ningbo
HS Code :
8428909090
Production Capacity :
1200pieces/Year
Description
2600mm High Hydraulic Scissor Lift Working Platform with Wheel Chassis and Emergency Lowering

Product Description
2600mm High Hydraulic Scissor Lift Working Platform with Wheel Chassis and Emergency Lowering
Mechanical data
Capacity 1000 Kg
Lift stroke 2000 mm
Lifting time 46 s
Closed height 600 mm
Weight 950 kg

This working platform will be used for welding activities to pipes of big machineries.
In the petrochemical industry there is lot of hanging pipes and all the closures most be checked frequently for leaking or closing problems.
A worker must do some welding activities on the platform at 2600 mm hight.



Marco Standard Components

All Marcolift standard lift tables are manufactured with high quality components to enhance reliability, durability and safety in operation.

Pump Bucher Motor Hoyer Denmark, protection IP55
Control Panel Marco standard control box Sealing Sweden, SKF
Cylinder Marco, with rapture valve and damping Limit switch USA, Suns
Safety frame Aluminum with limit switch Scissor arm Q345B, profile steel
Paint Finland, Tikkurila Hydraulic hose USA, Eaton




Marco Additional Component

In addition to the standard equipment of lift tables, it is possible to provide Marcolift lift table with a range of accessories to enhance safety, versatility, application and to simply handling.


Packaging & Shipping:
Main Loading Port: ShangHai or Ningbo
Production Delivery: 6-8 weeks (public holiday excluded)
