Specifications
Model Number :
CSK 146, CSK 176
Certification :
ISO
Brand Name :
ROSCHEN
MOQ :
1 pcs
Supply Ability :
1000 set
Price :
Negotiate
Packaging Details :
Wooden box
Place of Origin :
CHINA
Description

Csk 146/Sk6l 146 Triple Tube Wireline Core Barrel

Core Barrels

ROSCHEN coring systems stand for high quality and guarantee the best possible core recovery. In this field we have decades of experience. Due to the continuous improvement of our systems, you can always rely on their steadiness.

ROSCHEN Drilling offers a wide range of heavy-duty core barrel types for the fields of mining, oil and gas, as well as geotechnical engineering. Beside wireline core barrels, we supply double- and single tube core barrels. Optional variants with liner, multi-drill system or core orientation system are available. All wireline core barrels are equipped with the flexible Christensen latching head which assures a secure locking in every situation.

Wireline Core Barrels Specifications
System Borehole Diameter* Core Diameter Outer Barrel OD Depth Range**
CA 52,0 mm 27,0 mm 44,5 mm 2.100 m
CB 64,0 mm 36,5 mm 57,2 mm 2.100 m
CN 75,7 mm 47,6 mm 70,0 mm 2.000 m
CH 96,3 mm 63,5 mm 92,1 mm 2.000 m
CP 122,6 mm 85,0 mm 117,5 mm 2.000 m
NXB II 75,7 mm 47,6 mm 73,0 mm 2.100 m
HXB II 92,8 mm 61,2 mm 90,0 mm 2.300 m
CSK 146 146,0 mm 102,0 mm 140,0 mm 2.200 m
CSK 176 176,0 mm 132,0 mm 171,0 mm 1.800 m
SK 4 ¼" B 120,6 mm 69,0 mm 110,0 mm 2.500 m
SK 4 ½" B 123,8 mm 78,0 mm 114,3 mm 2.300 m
SK 5 ¾" 157,0 mm 88,9 mm 146,0 mm 4.500 m
SK 5 ½" B 161,9 mm 101,4 mm 152,4 mm 3.000 m
Notes
*Borehole diameter adjustable with core bit.
**Values calculated for original Christensen drill rods with safety factor 2.
