12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width
12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width
12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width
12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width
12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width
12X64 mesh 304 Stainless Steel Wire Mesh Screen Plain Dutch Weave 3m Width
Specifications
Brand Name :
Source Wire Mesh
Model Number :
12x64mesh
Certification :
ISO9001
Place of Origin :
Heibei,China
MOQ :
5Rolls
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Rolls/Week
Delivery Time :
5 days
Packaging Details :
1)Inside by waterproof bag, outside by cartons 2)OEM packing
Product name :
Plain dutch weave 12X64mesh,14X88mesh 304/316/316L stainless steel woven wire mesh
Materail :
stainless steel 304,Stainless steel 316/316L
Weave style :
plain dutch weave
Wire diameter :
0.024x0.0165mm
Width :
Usually1M, 0.5m-3m or customized, 1-2meters, 1m, 102mm
Length :
10-30mm
mesh size :
12x64mesh,8x85mesh,14x88mesh,20x150mesh
Usage :
oil, space flight, filter, Printing, chmical industry
Description

Plain dutch weave 12X64mesh 304/316/316L stainless steel woven wire mesh

Plain dutch weave 12X64mesh 304/316/316L stainless steel woven wire mesh product description:

Dutch weave filter mesh provides superior filtration capabilities for a wide range of applications, including pressure, fuel and liquid filters for the aerospace, petrochemical, pharmaceutical, mining and waste water treatment industries.

1. Material: 304 316 316L stainless steel wire mesh

2. Mesh count: 12x64, 20x300, 30x150, 40x200, 40x250, 80x400, 80x600, 200x14mm, 325x2300 etc

3. Roll width: 3', 1.0m, 1.2m etc

Customized outside diameter

4. MOQ: 3m2

5. Delivery time: within 5 days

Plain dutch weave wire mesh specifications
Item
Mesh
Wire diameter(Warp x Weft)
Hole size/Micron
KGS/M2
32#
8 x 62
0.63mm x 0.45mm
300
5.42
40#
10 x 79
0.50mm x 0.355mm
250
3.16
48#
12 x 64
0.58mm x 0.40mm
280
2.9
76#
19 x 140
0.315mm x 0.20mm
140
1.88
80#
20 x 300
0.35mm x 0.20mm
-
3.6
95#
24 x 110
0.355mm x 0.25mm
120
2.45
100#
25 x 140
0.28mm x 0.20mm
100
1.95
120#
30 x 150
0.25mm x 0.18mm
80
1.68
160#
40 x 200
0.20mm x 0.14mm
60
1.40
180#
45 x 250
0.16mm x 0.112mm
56
1.09
200#
50 x 250
0.14mm x 0.11mm
53
1.04
240#
65 x 330
0.11mm x 0.08mm
36
0.71
280#(1)
70 x 350
0.11mm x 0.08mm
35
0.72
280#(2)
70 x 385
0.11mm x 0.07mm
32
0.75
300#
78 x 700
0.11mm x 0.08mm
30
1.39
315#(1)
80 x 400
0.10mm x 0.065mm
40
0.62
315#(2)
80 x 600
0.10mm x 0.06mm
-
-
315#(3)
80 x 800
0.15mm x 0.04mm
-
-
320#
81 x 780
0.10mm x 0.07mm
30
1.22
354#
90 x 550
0.12mm x 0.05
-
-
