Advanced 51.2V home energy storage system with capacities ranging from 10KWH to 50KWH, designed for reliable solar energy storage and efficient power management.
| Cell Specification | LVB10WTC | LVB15WTC | LVB30WTC | LVB50WTC |
|---|---|---|---|---|
| Capacity | 200Ah | 280Ah | 280Ah | 314Ah |
| Rated Voltage | 3.2V | 3.2V | 3.2V | 3.2V |
| Internal Resistance | ≤0.2mΩ | ≤0.2mΩ | ≤0.2mΩ | ≤0.2mΩ |
| Combination Method | 16S1P | 16S1P | 16S2P | 16S3P |
| Electrical Characteristics | LVB10WTC | LVB15WTC | LVB30WTC | LVB50WTC |
|---|---|---|---|---|
| Nominal Voltage | 51.2V | 51.2V | 51.2V | 51.2V |
| Nominal Capacity | 200Ah | 300Ah | 580Ah | 980Ah |
| Energy | 10.24kWh | 15.360kWh | 29.696kWh | 50.176kWh |
| Useable Energy | ≥95% | ≥95% | ≥95% | ≥95% |
| Cycle Life | ≥5000 cycles | ≥10000 cycles | ≥10000 cycles | ≥11000 cycles |
| Standard Charge | LVB10WTC | LVB15WTC |
|---|---|---|
| Charge Voltage | 57.6V±0.2V | 57.6V±0.2V |
| Charge Current | 100A | 140A |
| Max. Charge Current | 200A | 200A |
| Standard Discharge | LVB10WTC | LVB15WTC |
|---|---|---|
| Continuous Current | 100A | 140A |
| Max. Pulse Current | 200A | 200A |
| Discharge Cut-off Voltage | 44.8V | 44.8V |
| Environmental & Mechanical | Specifications |
|---|---|
| Charge Temperature | 0℃ to 45℃ @60±25% R.H. |
| Discharge Temperature | -20℃ to 55℃ @60±25% R.H. |
| Water Dust Resistance | IP20 |
| Plastic Case | Sheet metal |
| Model | Dimensions (mm) | Weight (kg) |
|---|---|---|
| LVB10WTC | 630×460×265mm | About 89KG |
| LVB15WTC | 820×460×285mm | About 124KG |
| LVB30WTC | 1003×650×440mm | About 240KG |
| LVB50WTC | 1200×760×520mm | About 360KG |
Use Only The Highest Quality Batteries
Batteries that use the same standard as the country
Price advantage ≠ low quality: Large-scale production + direct purchase from the supply chain, procurement costs are 8-15% lower than peers, and tiered rebates are supported.
User Feedback: Users in multiple countries (e.g., USA, DE, UK, Australia) have validated its efficiency and reliability.
Typical Application: One household achieved a 30% reduction in electricity bills and 90% solar self-consumption after installation.
EXLIPORC NEW ENERGY (SHENZHEN) CO., LTD focuses on providing global energy storage systems, lithium-ion batteries, and inverters. We are a research and development, manufacturing, sales, operation and maintenance provider serving the complete industry chain.
Who are we?
We are based in Shenzhen, China, starting from 2011. We sell to North America (50.00%), Northern Europe (10.00%), Southern Europe (5%), Central America (10.00%), Southeast Asia (10.00%), Eastern Europe (10.00%), South America (5.00%). There are about 11-50 people in our office.
What can you buy from us?
We specialize in Lithium ion battery, Sodium ion battery, Home Energy storage system, LiFePO4 battery BMS.
Why should you buy from us not from other suppliers?
EXLIPORC NEW ENERGY (SHENZHEN) CO., LTD focuses on providing global energy storage systems, lithium-ion batteries, and inverters as a complete industry chain service provider.
How can we guarantee quality?
Always a pre-production sample before mass production; Always final inspection before shipment.
What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES.
Accepted Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF.
Accepted Payment Type: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow.
Language Spoken: English, Chinese, Spanish, Japanese, Portuguese, German, Arabic, French, Russian, Korean, Hindi, Italian.
