Specifications
Brand Name :
Huitong
Model Number :
HT014
CertifiPCion :
ISO9001
Place of Origin :
Guangzhou,China
MOQ :
1 Pcs
Price :
$350-700/pcs
Payment Terms :
D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 pcs per mounth
Delivery Time :
8-16 workdays
Packaging Details :
standard package
Condition :
New
After-sales service provided :
Online support,Video technical support
Warranty :
1 Year
Color :
customised
Type :
Mechanical quick hitch
Moving type :
Crawler Excavator
Product name :
excavator quick hitch
Material :
Q345B+NM400
Description

PC400 EX450 Custom Oem Hydraulic Quick Hitch Coupler For Excavator

product details:

Quick Hitch Coupler Advantages
Quick couplers (also called quick hitches) are used with construction machines to allow the rapid change of buckets and attachments on the machine. They remove the need to use hammers to manually drive out and insert the mounting pins for attachments. They can be used on excavator, mini excavator, backhoe loader and so on.
Benefits

- Grabs variable pin centres.
- Cinches up the slack as pins and coupler wear.
- Change attachments in minutes.
- Requires only a 1/2" drive ratchet to operate.
- Built-to-Last construction with T1 & AR400 Steel at all critical points.
- 1 set of Hardened Alloy pins included.
- Includes a 1 Year Limited Warranty.
Item
Unit
RQH-MINI
RQH-02
RQH-04
RQH-06
RQH-08
RQH-10
RQH-17
RQH-20
Carrier Weight
T
<4
4-6
7-8
12-18
19-24
25-32
33-40
50-80
Length(L)
mm
306-475
534-545
600
765
924-944
983-1050
1006-1173
1215-1425
Height(H)
mm
230-268
307
310
388
492
574
558-610
622-780
Width(W)
mm
175-242
258-263
270-280
353-436
449-483
543-568
606-663
640-740
C to C distance(A1)
mm
86-200
230-270
290-360
380-420
460-480
473-540
550-620
630-760
Arm With(W1)
mm
86-185
155-170
180-200
232-315
306-340
375-411
416-469
472-560
Equipping Distance(A2)
mm
90-140
208-318
340-450
340-486
256-390
413-590
520-590
570-780
Pin Diameter
mm
25-40
45-50
50
50-70
70-80
80-90
90-120
125-150
Weight
kg
60
100
110
250
500
650
850
1150
Working Pressure
kgf/
cm²
40-380
40-380
40-380
40-380
40-380
40-380
40-380
40-380
Oil Flow
I/m
10-20
10-20
10-20
10-20
10-20
10-20
10-20
10-20

Custom PC400 EX450 Crawler Excavator Quick HitchCustom PC400 EX450 Crawler Excavator Quick Hitch

1. Medium and high tensile steel is used throughout the body of the coupler making it very robust without adding unwanted weight.

2. With a tilt angle of ±45°

3. High quality material (Q345b) provide high steel toughness and good abrasive resistance.

4. Compact in design, virtually maintenance free,,Electric control system installed in cab , easy for operating.

5. Use security device of hydraulic control valve to ensure the safety.

6. Can change the accessories without disassembling the pin and axle

7.High Standard components and parts shows below:
