TM09VC Final Drive Assembly 14500160 14505081 For Volvo EC55 Excavator
TM09VC Final Drive Assembly 14500160 14505081 For Volvo EC55 Excavator
TM09VC Final Drive Assembly 14500160 14505081 For Volvo EC55 Excavator
TM09VC Final Drive Assembly 14500160 14505081 For Volvo EC55 Excavator
Specifications
Brand Name :
EC55
Model Number :
14500160
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
T/T, western Union, paypal or moneygram
Supply Ability :
10,000 unit per month
Delivery Time :
Within 3 working days after received your payment
Packaging Details :
Wooden
Product Name :
final drive assembly
Appliion :
excavator
Color :
black
type :
With gearbox
weight :
78kgs
parts number :
145050160
feature :
genuine motor
Standard :
100% new
Description


TM09VC Final Drive Assembly 14500160 14505081 For Volvo EC55 Excavator

Specifiions:

1, model: TM09VC
2, parts number 14500160 14505081
3, displacement (cc/rev): 47/27.1
4, working pressure(Mpa): 27
5, Brake Torque(kgf-m): 8
6, Gear Ratio(i): 53
7, output torque(Kgf-m): 1116/658
8, output speed (rpm: 37/56
9, applicable machine: EC55
10, weight: 78kgs

Overall dimension:
TM09VC Final Drive Assembly 14500160 14505081 For Volvo EC55 Excavator

item namemodelappliion machine model
travel motorMG26VPYC35, Kubota 45/35/32, B32, B37-2, SK30, Sk32, SK35, IS35J/S, A5/TB30/TB35/TB39
travel motorTM07VCDH60-7, DH55, R60-7,
travel motorTM09VCDH80-7, DH80Gold, PC60-6/7, E70B, SH60, PC75, Kato 250, SK60, Yanmar75, YC85, LG906/907, R80
travel motorTM09VC-52/43-10　
travel motorTM09VC-50/27-07PC78UU
travel motorTM18VCDH150, DH130
travel motorTM18V-68/43-02DH150, DH130, PC130-7, PC120-6, R135-7, R150-7, SK120, SH120, Kato450, Kato400, YC135, LG120,
travel motorTM22-77/45-01DH150, DH130, , R135-7, R150-7
travel motorTM22-77/45-02rotary drilling
travel motorTM40VCDH225-7, DH220-7, DH220-5, DH220-9, R260-7, R225-7, R220-5, R220-7, R210,R200,R225-9 EC210, SK210-8, Sk200-8
swing motorSM60DH60-7, DH55, R60-7,
swing motorSM220DH220-7, DH220-9, DH215-9, DH225-7, DH225-9, DH500
swing motorSM220Liugong220/225/922, R210(M2X150, R215-7(GMF151)

itemmachine modelitemmachine model
travel reducer/gearboxR200/ R210/ R220-5travel reducer/gearboxEX200-1
travel reducer/gearboxR215/R225-7, DH225-7travel reducer/gearboxEX200-5
travel reducer/gearboxDH258-7travel reducer/gearboxZAX200/210
travel reducer/gearboxR225-9, R210-7, SY215-7travel reducer/gearboxZAX200-3
travel reducer/gearboxDH215-9, DH225-9travel reducer/gearboxSK200/SK210-8, HD820-5
travel reducer/gearboxDH220-5, R260-5, LG200travel reducer/gearboxSK250-8
travel reducer/gearboxSK200-6Etravel reducer/gearboxDH300-7
travel reducer/gearboxPC200-6, PC220-6travel reducer/gearboxR305-7
travel reducer/gearboxPC120-6, PC100-6 PC110-7travel reducer/gearboxPC360-7, PC300-7
travel reducer/gearboxDH150, SY135-8travel reducer/gearboxDH370-7
travel reducer/gearboxPC120-5, PC100-5travel reducer/gearboxEC290B(old type)
travel reducer/gearboxSH265, E110Btravel reducer/gearboxPC60-7, PC78
travel reducer/gearboxEX100-1, EX120-1travel reducer/gearboxDH60
travel reducer/gearboxPC200-7travel reducer/gearboxR60-5, R60-7
travel reducer/gearboxSH200A3travel reducer/gearboxR80-7
travel reducer/gearboxSK230-6Etravel reducer/gearboxDH80-7
travel reducer/gearboxE320C, E318Ctravel reducer/gearboxZAX60-7
travel reducer/gearboxSH200A1, A2travel reducer/gearboxPC55/56



We could supply the following spare parts:
Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor,
swing machinery, swing motor, radiator and so on

Gear parts: reducer, gearbox, carrier box, shaft and so on

Engine parts: Piston, Liner, Piston ring, main bearing, connect rod bearing, water pump, turbocharger, crankshaft, camshaft, cylinder body, cylinder head, gasket head, gasket kit and so on.

Electric parts: throttle motor, solenoid valve, speed sensor, water temperature sensor, motor positioner, flameout solenoid valve and so on.

Undercarriage parts: track roller, carrier roller, sprocket, front idler, tack shoe, track link, tensioner spring and so on

Other parts: bucket, bushing, pin, seal kit, filter, cab and so on




Contact person: Tiger Wong (Mr)
Whatsapp: 008615558061878
Skype: tigertiger168886
Email: tigerfaye@hotmail.com
