Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
Specifications
Brand Name :
Belparts
Model Number :
CX160
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiated price
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
500 pieces per month
Delivery Time :
2-5days
Packaging Details :
Wooden
Model :
CX160
pump number :
K3V63DTP
part number :
11106231 KLJ0653 87341976
Part name :
case Hydraulic main pump
Highlight :
CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump
Product name :
hydraulic pump assy
Application :
excavator spare parts
Condition :
New/used
Description
Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit
The Belparts excavator hydraulic pump is a high-performance hydraulic power component specifically designed for various types of excavators. Incorporating advanced design concepts and manufacturing processes, it ensures stable and efficient hydraulic power output under various working conditions. Our hydraulic pump series covers the needs of excavators from small to large sizes, offering exceptional durability and reliability.
Product Specifications
Model CX160
Part Name Hydraulic Main Pump
Part Number 11106231 KLJ0653 87341976
Place of Origin Other Country
Condition Original & OEM
Warranty 6 months
MOQ 1 pcs
Production Capacity 1000pcs /Month
Standard or Nonstandard Standard
Payment Term L/C, T/T, Tradeassurance
Delivery Time 1-3 days (depend on order)
Means of Transport By Sea, Air or DHL
Guarantee We will check and send detailed pictures to buyers for confirmation

List of spare parts

# Part No Part Name Qty. Price request
P30359 O-RING 1
11106231 BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 6
P23681 BRAKE 6
P30892 SCREW 1
P45251 COMPOSITE SEAL 1
P937015 FLANGE 1
P1143323 VALVE POPPET 18
P3446067 GASKET 18
P1037446 SCREW 18
P236135 KEY 1
P3330170 SHIN 1
P34711 WASHER 6
P32933 SCREW 6
P532962 SCREW 48
P34711 WASHER 48
P3446066 OIL SEAL 1
P1446037 BACK-UP RING 1
P30351 O-RING 1
P3330153 FLANGE 1
P36261 RING, SNAP 1

Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit

The load-sensing hydraulic pump is an intelligent hydraulic pump designed based on the concept of "oil supply on demand", and its core principle integrates pressure feedback and flow regulation technology. In addition to the conventional oil suction and discharge mechanism (mostly axial piston structure), the pump body is also equipped with a load-sensing valve, a pressure compensator, and a variable control cylinder. When the excavator performs an action (such as boom lifting), the load pressure of the executive component (boom cylinder) is transmitted to the load-sensing valve through the feedback oil circuit. The valve compares the load pressure with the outlet pressure of the pump and calculates the pressure difference (usually maintaining a constant difference of 1-2MPa); then, the pressure compensator controls the action of the variable control cylinder according to this difference and adjusts the displacement of the pump - if the load pressure increases, the outlet pressure of the pump increases synchronously, and the displacement is automatically adjusted according to the flow demand, ensuring that the output flow exactly meets the movement speed demand of the executive component, and avoiding energy loss caused by excess oil overflowing through the relief valve.

Belparts CX160 K3V63DTP excavator main pump 11106231 KLJ0653 87341976 hydraulic pump fit

Frequently Asked Questions
1. What is the warranty time of the products?
The warranty time is 3/6 months based on the item details; We don't provide warranty time for original and used products.
2. What is your delivery time?
Generally, we will arrange the goods within 24 hours after your payment; if not in stock, the delivery time will be communied in advance, usually 3-7 days.
