Specifications
Brand Name :
Huilian
Model Number :
SB121 SB131 SB151
Certifiion :
ISO9001
Place of Origin :
China
MOQ :
1 Pieces
Price :
Negotiable
Payment Terms :
L/C, T/T, MoneyGram
Supply Ability :
10000 PCS per month
Delivery Time :
1-7days
Packaging Details :
Pallet and wooden cx
Part Name :
Hydraulic breaker/hammer
Model :
SB121 SB131 SB151
Material :
20CrMo, 42CrMo
Compatible carrier :
30-45Ton 40-55Ton 45-60Ton
Power :
the strike force and frequency are greater
Usage :
cconstruction/demolition/aggregate stone/mining
Chisel diameter :
165mm/175mm/180mm
power :
hydraulic
Shape :
Side type
Description
SB121 SB131 SB151 Hydraulic Breaker Side Type

High-performance hydraulic breaker/hammer designed for 30-45Ton, 40-55Ton, and 45-60Ton excavators in demolition, rock breaking, and construction Applications.

Product Specifiions
Attribute Value
Part Name Hydraulic breaker/hammer
Model SB121 SB131 SB151
Material 20CrMo, 42CrMo
Compatible Carrier 30-45Ton 40-55Ton 45-60Ton
Power High strike force and frequency
Usage Construction/demolition/aggregate stone/mining
Chisel Diameter 165mm/175mm/180mm
Power Source Hydraulic
Shape Side type
Detailed Product Parameters
All measurements in millimeters (mm) unless otherwise specified
MODEL WEIGHT(KG) LENGTH(MM) REQUIRED OIL FLOW L/MIN WORKING PRESSURE KG/CM M2 IMPACT RATE B.P.M HOSE DIAMETER CHISEL DIAMETER CHISEL LENGTH MM APPLICABLE EXCAVATOR M3
EB45 (SB20) 130 135 120 1265 1280 760 20-40 90-120 700-1200 1/2 45 450 0.03-0.1 1.2-3
EB180 (SB151) 4500 4500 4200 3800 3800 3300 250-340 160-180 250-320 1~1/4 180 1600 1.9-3.5 45-60
Available Spare Parts
  • Hammer Parts
  • Main Body
  • Back Head
  • Charging Valve
  • Cylinder
  • Socket Plug
  • Piston
  • Adapter
  • Valve
  • Valve Plug
  • Front Head
  • Grease Nipple
  • Rod Pin
  • Stop Pin
  • Rubber Plug
  • Ring Bush
  • Thrust Bush
  • Upper Bush
  • Front Cover
  • Tool Bush
  • Rod Moil Point
  • Chisel
  • Washer
  • Through Bolt
  • Side Rod
Breaker Types

Silenced (box) Type: Fully enclosed silent bracket, simple structure, few parts, low failure rate, easy maintenance.

Open (Top) Type: Small and flexible, suitable for indoor demolition, building reconstruction, etc.

Side Type: The king of power, the triangular bracket structure is stable, and the power of the breaker is maximized.

Applications
  • Mining: Mountainous areas, mining, grizzly bear crushing, secondary crushing
  • Metallurgy: Steel ladles, slag removal, furnace body dismantling
  • Railway: Mountainous areas, tunnels, bridge dismantling, roadbed compaction
  • Road: Repair, crushing of concrete pavement, foundation excavation
  • Urban landscape: Concrete crushing, water, electricity, gas and construction
  • Architecture: Demolition of old buildings, concrete crushing
  • Shipping: Ship hulls without mussels and rust
  • Others: Ice, broken permafrost, sand vibrators
Main Features
  • Cylinder & valves: Prevents wear with precision finishing treatment
  • Piston: Improved running properties; manufactured with high-quality nickel & vanadium alloy steel
  • Chisel: Exceptional performance and reliability; manufactured with high-quality alloy steel
  • Accumulator: Reduces irregular pulse pressure on hydraulic circuit; improved striking power
  • Oil seal: Increased hydraulic circuit design at the side of under pressure
Technical Specifiions
Model Required Oil Flow (L/min) Impact Rate (bpm) Working Pressure (kg/cm2) Rod Diameter (mm) Operating Weight (kgs) Applicable Carrier (ton)
HL1400 (SOOSAN SB81) 130-170 350-500 190-220 140 1825/1780/1750 20-26
HB20G (FURUKAWA HB20G) 100-150 350-600 180-210 135 1780/1720/1650 18-21
Warranty Information
Item Warranty Remark
Cylinder 12 months If no external force damage
Back Head 12 months Only crush and sand holes
Front Head (45-140)12 months,(150-210)6 months Only crush and sand holes
Piston (45-140)12 months,(150-210)6 months Except rusty
Main Valve (45-175)12 months,(185-210)6 months Except impurity scratch
