31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
Specifications
Brand Name :
KMP/ EC
Model Number :
31Q5-15030
Place of Origin :
China/Japan
MOQ :
1
Price :
USD;RMB
Payment Terms :
L/C, Western Union, MoneyGram, T/T
Supply Ability :
1000
Delivery Time :
1-7 days
Packaging Details :
Carton
Part Name :
Hydraulic Piston Pump
Use for :
Robex Excavators
Part Number :
31Q5-15030
Machine Model :
Robex R170 R180
Model :
KAWASAKL KPM Pump
Component :
Cylinder, Valve, Retainer, Shaft, Piston
Condition :
Brand New
Description

31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030

Robex Excavator main Pump Assy and Parts

31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030

Part No Qty Parts name Comments
31Q5-15030 [1] MAIN PUMP 532 XJBN-00407 [2] PISTON-SERVO
@ [1] MAIN PUMP UNIT 534 XJBN-00816 [2] STOPPER(L)
XJBN-00802 [1] SHAFT(F)-DRIVE 535 XJBN-00405 [2] STOPPER(S)
XJBN-00803 [1] SHAFT(R)-DRIVE NS548. XJBN-00360 [2] PIN-FEED BACK
XJBN-00804 [1] GEAR-1ST 702 XJBN-00817 [2] O-RING
XJBN-00429 [2] BEARING-ROLLER 710 XJBN-00387 [2] O-RING
XJBN-00805 [2] BEARING-NEEDLE 711 XJBN-00095 [1] O-RING
XJBN-00806 [4] SPACER-BEARING 717 XJBN-00818 [2] O-RING
XJBN-00807 [2] BLOCK-CYLINDER 719 XJBN-00819 [2] O-RING
XJBN-00425 [18] PISTON 724 XJBN-00044 [18] O-RING
XJBN-01278 [18] SHOE 725 XJBN-00045 [2] O-RING
XJBN-00808 [2] PLATE-SET 727 XJBN-00233 [2] O-RING
XJBN-00422 [2] BUSHING-SPHERICAL 728 XJBN-00097 [4] O-RING
XJBN-00421 [18] SPRING-CYLINDER 732 XJBN-00820 [2] O-RING
XJBN-00420 [2] PLATE-SHOE 774 XJBN-01029 [1] SEAL-OIL
XJBN-00419 [2] PLATE-SWASH 789 XJBN-00476 [2] RING-BACK UP
XJBN-00418 [2] BUSHING-TILTING 792 XJBN-00454 [2] RING BACK-UP
XJBN-00417 [2] SUPPORT 808 XJBN-00101 [4] NUT-HEX
XJBN-00809 [1] COVER-FR 824 XJBN-00821 [2] RING-SNAP
XJBN-00810 [1] COVER-RR 885 XJBN-00394 [2] PIN-VALVE PLATE
XJBN-01046 [2] CASING-PUMP 886 XJBN-00054 [4] PIN-SPRING
XJBN-00812 [1] BLOCK-VALVE 901 XJBN-00104 [2] BOLT-EYE
XJBN-01045 [1] PLATE(R)-VALVE 953 XJBN-00105 [2] SCREW-SET
XJBN-01044 [1] PLATE(L)-VALVE 954 XJBN-00392 [2] SCREW-SET
XJBN-00411 [8] SCREW 981 XJBN-00156 [1] NAME PLATE
XJBN-00813 [8] SCREW 983 XJBN-00455 [2] PIN
XJBN-00030 [2] PLUG 79 @ [1] EPPR VALVE
XJBN-00487 [4] PLUG *-2. @ [1] REGULATOR ASSY
XJBN-00814 [2] PLUG *-5. XJBN-01018 [1] PTO UNIT
XJBN-00032 [15] PLUG 5 XJBN-01020 [1] PTO ASSY
XJBN-01572 [1] PISTON SUB ASSY 5-1. XJBN-00160 [2] SCREW-SOCKET
XJBN-01048 [1] CYLINDER SUB ASSY-RH 5-2. XJBN-00725 [4] SOCKET-FLANGE
XJBN-01047 [1] CYLINDER SUB ASSY-LH 5-3. XJBN-00031 [1] PLUG
XJBN-00800 [1] SWASH PLATE SUB ASSY 5-4. XJBN-00837 [1] O-RING
XJBN-00801 [1] TILTING PIN SUB ASSY 5-5. XJBN-00387 [1] O-RING
@ [AR] NOT SUPPLIED PARTS 5-6. XJBN-00046 [1] O-RING
XJBN-00387 [2] O-RING 5-7. XJBN-01023 [1] PIN-SPRING
XJBN-00095 [1] O-RING *-51. @ [1] PUMP-GEAR


Hyundai Excavator Hydraulic Component Parts

31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
31Q5-15030 Hyundai Excavator Main Pump Robex Digger Hydraulic Parts 31Q515030
