YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
YM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless
Specifications
Brand Name :
POOYERT
Model Number :
320X90X52
Certification :
ISO9001:2015
Place of Origin :
SHANGHAI
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 pieces per month
Delivery Time :
10-20 days
Packaging Details :
wood pallet or container depends on the quantity
Product name :
Rubber Crawler for Excavators
Width :
320mm
Pitch :
90mm
Links :
52
Total Length :
4680mm
Material :
Rubber& steel
Technology :
continuous with jointless
Color :
black
Description

Product Description

Black Rubber Track(320X90X52 ) for YM C20R Excavator


Product Information
1.Name of commodity Rubber Track 320x90x52 for YM C20R
2.Width 320mm
3.Pitch 90mm
4.Links 52
5.Total Length 4680mm
6.Weight 147.16kg
7.Material Rubber and Steel
8.Steel cord type Jointless
9.Warranty 1 year under normal use

YM C20R 320X90X52 Excavator Rubber Tracks Continuous With JointlessYM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless

Extreme Durability & Performance

Our joint free track structure, Special designed tread pattern, 100% virgin rubber,and one piece forging insert steel

result extreme durability & performance and longer service life for construction equipment use. Tracks perform a
high level of reliability and quality with our latest technology in mold tooling and rubber formulation.

Delivery and Packing

Production time is around 10-15 days for 2 pieces,the actual time need to be confirmed before order.
We need to check the schedule of the rubber track orders when you plan to order.
After finished production,the rubber tracks will be packing on the pallet after QC prodedure.
The pallet we use is standard export for sea shipping.
Covered with stretch film and rope.


YM C20R 320X90X52 Excavator Rubber Tracks Continuous With JointlessYM C20R 320X90X52 Excavator Rubber Tracks Continuous With Jointless

Rubber Track Size List

Please noted that, the parameter just show the part of our size range, if you cannot find your size, please kindly inform us by email or other ways, we will customize for you.

​

Size KG/link   Size KG/link   Size KG/link   Size KG/link
130*72 0.41   300*52.5K 1.68   450*71 4.45   U320*90 2.94
150*60 0.49   300*52.5KA 1.6   DW450*71 4.82   320*100 2.67
150*72 0.55   300*52.5N 1.38   450*73.5 4.56   320*100W 3.01
170*60 0.48   300*52.5NKZ 1.71   450*76 5.3   330*79 1.42
180*60 0.47   300*52.5W 1.23   450*81N 4.47   350*90 1.9
180*72 0.64   300*52.5KW 1.73   450*81W 5.07   350*100 3.65
180*72K 0.87   KB300*52.5 1.71   KB450*81.5 5.28   U380*90 3.81
180*72YM 0.85   KB300*52.5N 1.55   K450*83.5 5.48   400*90 2.22
180*72KM 0.87   JD300*52.5 1.54   Y450*83.5K 5.54   L400*90 2.20
V180*72K 0.97   300*52.5WAV 1.7   K450*163 10.47   420*100 5.43
H180*72K 0.77   300*52.5WKZ 1.75   485*92 8.01   450*90 4.07
190*60 0.5   E300*52.5K 1.76   K500*71 5.45   450*90N 2.75
190*72 0.76   300*52.5NA 1.38   500*92 7.93   M450*100 5.81
200*72 0.92   300*53K 1.54   500*92W 8.1   450*110 6.9
200*72K 1.07   300*53KA 1.5   B180*72 0.89   500*90 5.54
WD200*72 0.55   300*55 1.92   B180*72A 0.71   500*100 6.42
Y200*72 0.69   300*55YM 1.85   B250*72A 1.03   600*100 8.54
230*48 1.05   300*55.5K 1.97   B300*84 2.87   600*125 10.38
230*48K 0.98   300*71 3.3   300*84N 2.8   650*110 13.43
230*48KZ 1.06   300*72 1.77   T300*86 3.13   650*120 14.1
230*48A 0.87   DW300*72 0.99   B320*84 2.88   650*125 15.67
230*72 1.09   BA300*72 1.27   B320*86 2.71   700*100 11.33
230*72K 1.35   320*52.5 1.69   B320*86R 2.84   T700*100 12.02
WD230*72 0.7   320*54 1.82   B320*86C 2.84   700*125 14.33
B230*72K 1.27   B320*55K 2.08   B320*86CM 2.78   750*150 21.48
V230*72K 1.37   Y320*106K 3.44   B320*86SB 2.81   800*125 19.36
230*96 1.68   350*52.5 1.89   ZB320*86 2.89   K800*150 22.56
230*101 1.91   E350*52.5K 1.93   T320*86K 3.13   T800*150 22.5
250*47 1.13   350*54.5K 2.26   ZT320*86K 3.51   M800*150 20.45
250*48 0.93   350*54.5KA 2.25   T320*86C 3.31   800*150KM 24.02
250*48.5K 1.13   B350*55K 2.13   T320*86SB 3.36   800*150 23.59
250*52.5 1.04   350*56 2.06   T320*86KA 3.51   900*150 31.18
250*52.5N 1.26   350*72.5KM 2.86   T320*86KD 3.51   1000*150 33.75
250*52.5K 1.31   350*75.5K 3.58   T320*86KTF 3.51   H280*72 1.69
250*72 1.11   350*108 3.92   B400*86ZZS 3.46   350*73 3.45
B250*72 1.05   350*109 4.12   B400*86C 3.56   330*84 1.23
B250*72CT 1.63   Y370*107K 4.68   B450*84 3.96   KU330*79 0.87
E250*72 1.37   400*72.5N 3.01   B450*86 3.98   KU400*84 1.44
250*96 2.27   400*72.5NKZ 3.6   B450*86C 4.09   6*3.5*28 0.5
250*109 2.05   400*72.5W 3.51   B450*86SB 4.18   10*3.5*28 0.93
260*52.5K 1.42   400*72.5WKZ 3.77   B450*86R 4.12   280*102*37 1.36
260*55.5K 1.49   400*72.5KW 3.33   B450*86CM 4.13   380*102*42 1.9
Y260*96 1.78   Y400*72.5K 3.71   ZB450*86ZZS 4.08   457*101.6*51 2.37
260*109 2.75   KB400*72.5K 3.44   B450*86D 4.05   457*101.6C*51 2.34
V265*72 1.32   KB400*72.5KA 3.4   T450*100K 4.91   510*101.6*51 2.9
E280*52.5K 1.75   400*73 4.23   T450*100KTF 4.9   356*152.4*46 4.81
280*72 1.44   400*74 3.4   ZT450*100K 5.1   460*225*36 7.79
Y280*106K 3.04   400*75.5K 4.08   T450*100C 5.18   483*152.4*52 6.07
K300*109 3.61   Y400*107K 4.95   T450*100SB 5.14   18"*6.75"*48 9.15
300*109N 3.26   K400*142 7.12   T450*100KD 5.1   25"*6.75"*48 12.73
300*109W 3.21   400*144 7.75   K500*146 9.97   30"*7"*54 15.85
300*109WK 3.44   Y400*144K 7.41   320*90 2.83   36"*7"*54 18.78

​

​

Characteristics of rubber track

1).Less damage to the ground surface


2).Low noise


3).High running speed


4).Less vibration;


5).Low ground contack specific pressure


6).High tractive force


7).Light weight


8).Easy to change
