Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h
Specifications
Brand Name :
Excar
Model Number :
A1S2+2
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
300 pcs per month
Delivery Time :
about 15 working days
Packaging Details :
20' container
Motor :
3.7KW ADC brand
Controller :
350A USA Curties
Battery :
48V Trojan battery 6*8V
Charger :
17A regular
Transaxle :
Italy graziano axle
Tyre :
205/50-10 Tyre
Color :
Yellow
Brand :
EXCAR
Description

EXCAR yellow 4 seater without roof golf cart china electric golf cart for sale

Configuration

Item Description
System DC system AC system
Controller Curtis controller 1266A-5201, 275A, imported from USA directly Curtis controller 1234E-5221, 275A, imported from USA directly
Motor ADC brand Separately excited
DC motor 48V 3.7kw		 ADC brand Separately excited
AC motor 48V 3kw
Battery Trojan battery, T875,8V*6pcs, imported from USA directly Trojan battery, T875,8V*6pcs, imported from USA directly
Transaxle Italian GRAZIANO axle
with gear ration 1:12		 Italian GRAZIANO axle
with gear ration 1:16
Charger High Frequency onboard charger
48V/17A regulator		 High Frequency onboard charger
48V/17A regulator

Performance

Item Description
system DC system AC system
Passenger Capacity 2 2
Climbing capacity(full load) 30% 35%
Max. forward speed 23km/h 45km/h
Endurance mileage 70-90km 80-90km
Charging time 8-10 hours 8-10 hours
Max. loading weight 360kgs 360kgs
Min. turning radius 2.9m 2.9m
Max. movement after brake at speed of 20km/h ≤4m ≤4m

* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
*2) Range will vary depending on temperature, grade, payload and driving style.

Dimensions

Item Description
Overall dimensions (L x W x H) 2641x1219x1727mm
Ground clearance 114mm
Wheelbase 1670mm
Front wheel tread (mm) 860mm
Rear wheel tread (mm) 970mm
Floor mat Anti-skidding rubber
Rear basket Plastic
Golf bag holder Plastic support with nylon strap
Dashboard Black plastic material, battery power indicator, ignition key on it
Beverage holders 4 pcs cups holders, 2 pcs for each side
Side trim Plastic, black
Score card holder On the steering wheel


Product showroon



Four Seats Mini Electric Utility Carts , Max. Forward Speed 23km/hFour Seats Mini Electric Utility Carts , Max. Forward Speed 23km/h

Service

1.For all your inquires about us or our products, we will reply you in detail within 24 hours.

2. We offer OEM services. Can print your own logo on product ,can customize the electrical golf cart body colour and other things.

3.Our director who developed the golf cart and he is the Doctor for engineering,and he has more than 10 years experience with the cart,so any carts problem you can contact him.He can speak fluent English to solve any your problem.

FAQ

1.Can you customize the cart according to our special request?
Yes,we can customize the cart according to your request unless some complex parts we hard to make.

2.What is your MOQ?
You can order just 1 unit .But if your order is big, we will provide you with a discount.

3.Can we put the Logo we designed on the cart?
Yes, you can put your own Logo on the cart.

4.What is your lead time for production?
The typical lead time of our cart is 15 days.

5.What kind of warranty Excar provides?
Non-artificial damaged products,shifting for a year or one year repair.


Contact person

Contact: Pauline Liu
Dongguan Excar Electric Vehicle Car Co.,ltd
Mobile: +86-13546943585

www.excar.com.cn
