Specifications
Brand Name :
EWT
Max Load Quantity(cells) :
16
Battery Type :
Semi-solid state
Cycle Life :
6000 cycles, 6000 cycles
Application :
Electric Power Systems, Wall-mounted battery
Model Number :
EWT-LFP5KWH-16P
Weight :
55kg
Operating Temperature(℃) :
-20~60
Place of Origin :
Guangdong, China
Cathode Materials :
LiFePO4
Voltage :
51.2V
Capacity :
100Ah
Energy :
5KWh
BMS :
Built-in Intelligent BMS
Communication :
RS485/CAN
Warranty :
3 Years
Type :
Wall-mounted
Output Wattage :
5KW
Price :
$550/sets 1-9 sets
Description

Wall-mounted Home Energy Storage Battery 5KWh 51.2V 100Ah Lifepo4 Battery for Energy System Factory Sales Smart BMS 6000 Cycles

Product Description

Item

Parameters

Remark

Typical Capacity

100Ah

25℃,0.2 C5A discharge

Nominal Voltage

51.2V

25℃,Average Voltage at 0.2 C5A discharge

Charge current

Max 100A

customrized

Charge cut-off voltage

54.0±0.50V

CC/CV

Charge time

5-6 hours

customrized

Working current

50A

customrized

Max working current(15S)

100A

customrized

Peak Working Current(2S)

150 A

customrized

Over current protection

200±10A

Cut off load or charge active

Over charge protection

3.6±0.025V

Single cell

Over discharge protection

2.0±0.025V

Single cell

Balance current

optional

Weight

About 56.5 kg

approximation

Storage temperature

0-40℃

Best 20±5℃ for long-time storage

size

Length

200

Units: mm(customrized)——

Width

560

thick

280
