Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Programmable Xenon Arc Weathering Test Chamber for Accelerated Sunlight Aging and Climate Simulation
Specifications
Brand Name :
Sinuo
Model Number :
SN884B
Certification :
Calibration Certificate (Cost Additional)
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10 Sets Per Month
Delivery Time :
30 Days
Packaging Details :
Export packing
Test Chamber Size (D×W×H) :
490 × 790 × 400 mm
Overall Dimensions (D×W×H) :
1130 × 1020 × 1800 mm
Lamp Type :
Air-cooled xenon arc lamp
Lamp Lifetime :
≥ 1200 hours
Humidity Range :
Light cycle 20–75% RH; dark cycle 45–95% RH
Humidity Deviation :
±5% RH
Irradiation Area :
3240 cm²
Sample Inclination :
10°
Description
Xenon Arc Weathering Test Chamber for Accelerated Light Aging and Sunlight Simulation Testing
Compliance Standards
  • The equipment complies with the following standards:
  • GB/T 16422.2-2014 — Plastics — Exposure to laboratory light sources
  • ISO 4892-2 — Plastics — Methods of exposure to laboratory light sources — Part 2: Xenon-arc lamps
  • ISO 11341 — Paints and varnishes — Artificial weathering and exposure to artificial radiation — Filtered xenon-arc radiation
  • AATCC TM16 — Colorfastness to Light
  • AATCC 169 — Weather Resistance of Textiles: Xenon Arc Method
  • GB/T 8427-2008 — Textiles — Tests for color fastness — Color fastness to artificial light: Xenon arc
Product Overview

Designed for artificial weathering and light aging tests simulating natural sunlight exposure. The chamber is suitable for automotive interiors, plastics, paints, coatings, electronic instruments, textiles, printing and dyeing materials, dyes, decorative materials, wood flooring, safety helmets, leather, petrochemical products, rubber, and other related materials.

By setting xenon lamp irradiance, temperature, humidity, water spray, and light/dark cycles inside the chamber, the equipment provides standardized simulated natural environments to evaluate material performance changes such as fading, aging, softening, hardening, and cracking.

Technical Parameters
Item Specification
Model SN884B
Test Chamber Size (D*W*H) 490 * 790 * 400 mm
Overall Dimensions (D*W*H) 1130 * 1020 * 1800 mm
Lamp Type Air-cooled xenon arc lamp
Lamp Lifetime ≥ 1200 hours
Irradiance Control Wavelengths 340 nm, 420 nm, 300–400 nm
Irradiance Range 0.35–1.00 W/m² @340 nm; 0.45–2.40 W/m² @420 nm
Irradiance Control Built-in solar eye, closed-loop PID automatic adjustment
Filter System Special glass filters simulating daylight or window glass environments
Air Temperature Range 35–65 °C (adjustable)
Black Panel Temperature (BPT) Light cycle 55–100 °C; dark cycle 35–65 °C
Black Standard Temperature (BST) Light cycle 60–110 °C; dark cycle 35–65 °C
Temperature Deviation ±3 °C
Humidity Range Light cycle 20–75% RH; dark cycle 45–95% RH
Humidity Deviation ±5% RH
Irradiation Area 3240 cm²
Sample Inclination 10°
Sample Capacity Standard finished parts or 3D specimens
Light/Dark Cycle 0–9999 h programmable
Spray Cycle 0–9999 h programmable
Spray Method Surface spray
Number of Lamps 3 units
