600kw DC Fast Electric Car Charging Stations Split Type OEM
600kw DC Fast Electric Car Charging Stations Split Type OEM
Specifications
Brand Name :
RUISU
Model Number :
RSDC1000-600KW-FYL
Certification :
CE ISO
Place of Origin :
GUANGZHOU,CHINA
MOQ :
1
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1500 Pcs Per Month
Delivery Time :
20-30 DAYS
Packaging Details :
Dimension (H*W*D)(mm) 1193*1100*2197
Input Frequency (Hz): :
45/66 Hz
Max. Output Current (a) :
0-600A (Single Gun)
Cooling Types :
Air Cooling+ Force Liquid
Description

600kw DC EV Liquid-Cooled Charging Stations Split Type Electric Vehicle Charger


Advantages:
1. Adopt intelligent liquid cooling technology and dual-circulation cooling circuit, allowing the coolant to directly reach the charger terminal and making the charging speed not decreased even the temperature is lower than 55 °C.
2. The coolant in the liquid cooling system is an organic synthetic liquid that does not freeze at minus 45°C; the cooling source module is equipped with monitoring and alarm devices for the working pressure, flow and temperature of the coolant.
3. Satisfy the needs of high-power and fast charging of electric vehicles, realize 100% SOC of the vehicle within 10 minutes, and solve the customer's pain point of long charging time.

Technical Parameters:

Product Model RSDC1000-600KW-FYL main cabinet
Dimensions 1193*1100*2197mm (main cabinet)
(width x thickness x height) 800*530*1822mm (sub-cabinet)
AC Input Voltage Range 380V+15%
AC Input Frequency 45~66Hz
Output voltage 200-1000VDC (300-1000VDC constant power)
Maximum Output Current 0-600A; efficiency: > 96%
Metering Method DC amperemeter metering
Altitude Height <2000m
Operating Temperature -20°C~50°C
Communication Interface 4G, RS485, CAN, Ethernet
Charger Length 600A liquid cooling gun, with the length of 5m
Degree of Protection Ip54 for plug and dust cap; IP55 for plug and socket box
Cooling Mode Forced air cooling + liquid cooling; cooling fan power: 90W
Dimensions of Cooling Source Module 550*200*600mm

600kw DC Fast Electric Car Charging Stations Split Type OEM

After-sale Service:
1. Two years warranty for the whole body.
2. If any parts break during the period, it's free replacement.
3. Professional technical engineer support for installation&operation and communication connection assistance between your app and our OCPP platform.
Additional Options:
1. Customized cable length.
2. Customized charger connector.
3. Customized Box color and customized logo.
