11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
11kW Three Phase Portable EV Charger with 16A CEE Plug Fast AC Charging Unit
Specifications
Model Number :
ACH-QE11
Maximum Power :
11kW
MOQ :
1piece
Delivery Time :
15-25 days after deposit
Rated Current :
6A-32A adjustable
Payment Terms :
T/T,L/C,PayPal,Western Union
Cable Length :
0.5m CEE
Brand Name :
ANS
product name :
Portable EV Charger Three Phase 16A
Packaging Details :
Carton with EVA protective box, 460x350x165mm per set
Place of Origin :
Zhejiang, China
Rated Voltage :
400V AC
Price :
Negotiable
Protection Rating :
Control box IP66, plug end IP55
Supply Ability :
30000 Pieces per Month
Connector :
Type 2
Certification :
TUV-Mark / CE, IEC 61851-1, EN 18031
Input Plug :
CEE (three phase)
Description

Overview

The Q series electric vehicle charger offers an innovative 2-in-1 design that seamlessly transitions between a portable unit and a wallbox. Operating on a three-phase 400V AC power supply, this 11kW fast AC charging unit is equipped with a red 16A CEE plugand a Type 2 connector (compliant with IEC 61851 standards). It delivers safe, reliable Mode 2 charging for European standard EVs whether at home, in the office, or during travels. Weighing just 3.4kg, its lightweight PC double-layer structure makes it effortless to pack, install, or carry on the go.

Key Features
  • 11kW Three Phase Speed: A 400V three phase input lifts output to 11kW, restoring range several times faster than a common single phase lead.
  • Balanced Phase Loading: Power is drawn across three phases, which reduces strain on any single conductor compared with equivalent single phase charging.
  • CEE Three Phase Plug: A robust industrial connector seats firmly in a matching outlet for repeatable, vibration resistant connections.
  • Adjustable Charging Current: Panel and app controls allow the draw to be set between 6A and 32A so installations stay within supply limits.
  • App Scheduling And OTA: Set off peak charging windows and receive over the air firmware updates through the companion mobile application.
  • Weather Sealed Enclosure: The IP66 control box and flame retardant PC body tolerate dust, rain and temperature swings on outdoor walls.
Technical Specifications
Parameter Specification
Charging Mode Mode 2 portable / wallbox (IEC 61851)
Connector Type 2 plug (IEC 61851-2024)
Rated Voltage 230V / 400V AC
Rated Current 6A / 8A / 10A / 13A / 16A / 24A / 32A
Display 2.8 inch LCD screen
Communication PWM + WiFi / Bluetooth app
Residual Current Device Type B (IΔN = 30 mA) + DC (IΔNDC = 6 mA)
Insulation Resistance ≥500MΩ (DC 500V)
Dielectric Strength 2000V AC / 1min, no breakdown
Flammability Rating UL94 V-0
Operating Temperature -30°C ~ +50°C
Storage Temperature -40°C ~ +65°C
Altitude <2000 meters
Housing Material Flame-retardant PC
Color Grey + black
Cable Material TPU (flexible, cold resistant)
Plug Durability >10,000 mating cycles
Packaging Dimensions 460 x 350 x 165 mm
Maximum Power 11kW
Input Plug CEE three phase
Net Weight 3.4 KG
Smart Connectivity & Custom Control
Featuring a clear 2.8-inch HD LCD display, users can view real-time charging status, including current, voltage, and temperature at a glance. The charger supports both Wi-Fi and Bluetooth mobile app integration, allowing you to schedule charging sessions to save energy costs, perform OTA firmware updates, or enable plug-and-charge convenience. Current can be flexibly adjusted (6A, 8A, 13A, 16A) via the app or directly through the physical panel button. Furthermore, it supports optional DLB (Dynamic Load Balancing) via CT rings or Wi-Fi communication boxes, as well as OCPP expansion via 4G/Wi-Fi for fleet and commercial management.
