22kW 3 Phase 480V Type 2 To Type 2 EV Charging Cable 10m IP55
22kW 3 Phase 480V Type 2 To Type 2 EV Charging Cable 10m IP55
22kW 3 Phase 480V Type 2 To Type 2 EV Charging Cable 10m IP55
22kW 3 Phase 480V Type 2 To Type 2 EV Charging Cable 10m IP55
22kW 3 Phase 480V Type 2 To Type 2 EV Charging Cable 10m IP55
22kW 3 Phase 480V Type 2 To Type 2 EV Charging Cable 10m IP55
Specifications
Brand Name :
ANS
Model Number :
ANSAG-T2-T2-32A-3-ST
Certification :
TUV/CE,ROHS,REACH
Place of Origin :
China
MOQ :
1pcs
Price :
USD70-100
Payment Terms :
T/T, Western Union,Paypal, L/C, L/C
Supply Ability :
600pcs/day
Delivery Time :
10-30days
Packaging Details :
Carton box. Carton size: 43*43*21cm
Name :
Type 2 EV Charging Cables
Cable Spec :
5*6+2*0.5mm2
Cable color :
Black, green ,orange or customized
Plug color :
Grey, green, orange, white
IP Grade :
IP55
charge power :
max 22kW
OEM Color :
Yes
Description

22kW 3 Phase 480V EV Charger Type 2 EV Charging Cable for Electric Car Charging Leads

The ANS ANSAG-T2-T2-32A-3-ST is suitable for all modern electric vehicles with Type 2 sockets, which are now the EU standard and used by most car manufacturers. The cable has a charging capacity of up to 22kW, 32A 3phase. The cable would reach up to IP55 under working standard.

Characteristics

Type 2 cable - compatible with all type 2 charging stations

our high-quality type 2 cable is suitable for charging all purely electric vehicles and plug-in hybrids with type 2 plugs, which is the standard in Europe. if the vehicle is not supplied with a charging cable. The type 2 cable can also be connected to all other charging stations (e.g. in public areas) via a type 2 socket, thus ensuring optimum charging comfort at home and on the road with a maximum charging power of 32 A. It is also ideal as a second cable if the charging cable is to be permanently stuck at home. Depending on your personal habits, you can choose from the cables with a length from 3M to 10M.

Specification:

product application

Electric vehicle

rated current

32A

rated voltage

480V

Mechanical life

no-load plug >10000 times

Withstand voltage

2500V

Insulation resistance

>1000MΩ (DC500V)

Operating temperature

-30 ºC ~ +50 ºC

Cable Size

5*6+2*0.5mm2
