ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
ZA06 European Edition – Type 2 Portable EV Charger with 22kW 3‑Phase Support, LCD Display & Multi‑Intelligent Protection (CE & TÜV Certified)
Specifications
Payment Terms :
T/T
Cooperation Options :
Whole unit or SKD/CKD
Temperature :
-30℃~+50℃
Charging Speed :
Up to 30 miles of range per hour
Supply Ability :
3,000 units per month
Power :
3.5KW/7KW
Working Temperature :
-30℃~+50℃
Material :
Copper
Display :
2.8-inch LCD+ indicator light
Ip Degree :
IP65
Model Number :
ZA06
Model :
ZA06
Iccb Size :
L218xW100xH60 (mm)
Delivery Time :
25~35 days
Input Voltage Rating :
AC200-250V
Charging Cable :
3x2.5mm²+0.5mm²
Cable Protection Rank :
IP55
Control Box Size :
L220XW100XH60mm
Warranty :
2 years manufacturer warranty
Place of Origin :
PRC
Design Type :
Private Mold
MOQ :
200 units，can be flexible
Manufacturing :
In-house
Function :
Charging, Discharging
Brand Name :
OEM/ODM/White-label
Charger Type :
Portable EV
Current :
16A32A
Description
ZA06 Electric Vehicle Charger
Key Features

• Multi‑Intelligent Detection – Real‑time voltage/current monitoring and precise power calculation for comprehensive safety.

• Intelligent Temperature Control – Prevents overheating, ensuring stable and safe operation even during high‑power sessions.

• Wide Power Range – Available in 3.5kW, 7kW, 11kW, and 22kW (three‑phase) to suit different charging needs.

• 1.9‑inch LCD Display – Clearly shows standby, charging, fault status, and real‑time parameters; complemented by an indicator light.

• Multiple Charging Modes – Supports plug‑&‑charge, APP/button scheduling, auto‑full charge, and timed charging.

• 4‑Level Adjustable Current – With memory function (auto‑restores last setting on power‑up) for flexible and convenient charging.

• Remote O&M Platform – Enables health diagnosis, fault early warning, and OTA upgrades, reducing maintenance costs.

• WiFi & Bluetooth Connectivity – Full APP control, real‑time monitoring, and remote scheduling.

• IP66 Weatherproof – Dust‑tight and protected against powerful water jets, ideal for all European climates.

• Safety Certifications – CE, TÜV‑tested, RoHS 2.0 compliant, and built‑in Type A+DC 6mA leakage protection (CCID).


Technical Specifications


Parameter Specification
Model ZA06‑EU
Connector Type Type 2 (IEC 62196‑2)
Charging Mode Mode 2 (IC‑CPD) & Mode 3 compatible
Operating Voltage AC230V ±10% (single‑phase) / AC400V ±10% (three‑phase)
Operating Frequency 50Hz ± 1Hz
Rated Power (selectable) 3.5kW / 7kW / 11kW
Rated Current (selectable) 16A (single‑phase) / 32A (single‑phase) / 16A (three‑phase)
Adjustable Current Levels 8A‑10A‑13A‑16A (single‑phase 16A) / 16A‑20A‑24A‑32A (single‑phase 32A) / 8A‑10A‑13A‑16A (three‑phase 16A)
Display 1.9‑inch LCD (standby, charging, fault, real‑time data) + indicator light
Communication WiFi & Bluetooth (APP control, OTA, remote diagnostics)
Input Cable Length 0.5m
Output Cable Length (optional) 5m / 7m / 7.5m
Operating Temperature –30°C to +40°C
Operating Humidity 5% ~ 95% RH (non‑condensing)
Ingress Protection IP66 (dust‑tight, protected against powerful water jets)
Leakage Protection Type A + DC 6mA (CCID built‑in) – EU compliant
Control Box Dimensions 220mm × 100mm × 60mm
Weight < 5.8 kg
Certifications CE (LVD & EMC), TÜV‑tested, RoHS 2.0, IP66


Certifications & Compliance

• CE Marking – Complies with LVD (2014/35/EU) and EMC (2014/30/EU) directives.

• TÜV‑tested – Meets rigorous safety and performance standards.

• EN IEC 61851‑1 – General requirements for conductive charging systems.

• EN 62752 – In‑cable control and protection device (IC‑CPD) for Mode 2 charging.

• EN 62196‑2 – Type 2 AC charging interface standard.

• RoHS 2.0 – Restriction of hazardous substances.

• IP66 – Weatherproof for outdoor use in rain, snow, and dust.


Why Choose ZA06 for Europe?

  • • Full Compliance with 2026 EU Regulations – The ZA06 uses the standard Type 2 connector (IEC 62196‑2) required for all new private AC portable chargers above 3.7kW. From September 2026, non‑compliant chargers will be blocked at EU customs – the ZA06 is already ready.

  • • High‑Power 22kW Three‑Phase – Perfect for European homes and businesses with three‑phase supply, significantly reducing charging time.

  • • Multi‑Intelligent Protection – Not just temperature, but also over‑current, over‑voltage, short‑circuit, and leakage protection (Type A+DC 6mA) – all built‑in.

  • • Designed for Harsh Climates – Operates from –30°C to +40°C with IP66 rating, reliable across Scandinavia to Southern Europe.

  • • Smart Connectivity – WiFi/Bluetooth with APP control, OTA updates, and remote diagnostics – meets EU smart charging trends.

  • • CE + TÜV – One certification covers all EU countries, no per‑country re‑certification needed.
