Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
Specifications
Brand Name :
OEM
Model Number :
FC Fiber Optic Adapter
Certification :
CE/ROHS/ISO
Place of Origin :
China
MOQ :
500Pieces
Price :
Negotiable
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
5000pieces/week
Delivery Time :
3~10days
Packaging Details :
PP bag and carton
connector :
FC/UPC, FC/APC
Sleeve Material :
Ceramic or Brozen Sleeve
Cores :
simplex, duplex
Tensile Strength :
200 to 600N
Mode :
single mode, multi mode
Application :
FTTH FTTB FTTX Network
Description

Adapter FC Fiber Optic Cable Assemblies , SM Metal FC

Fiber Optic Adapter

1. Features

1). Accord with the standard of ANSL,Bellcore,TIA/EIA,IEC

2). With high precise dimension

3). Ceramic or bronze house

4 ). Low insertion(<0.2dB),hign return loss(≥50dB)

5). Changebility is more than one thousand,repeatibility is less than 0.2dB

2. Application

1). CATV

2). Telecommunication networks

3). Test equipment

4). Metro

5). Local Area Networks(LANs)

6). Data processing networks

7). Premise installation

8). Gigabit Ethernet

9). Active device/Transceiver

10). Fiber Optic Subscriber network transimission/switching equipment

3. Technical Specifications

Type

Insertion loss(db)

Tensility resist(g)

Inser and pull times

Temperature(℃)
FC

PC

< 0.2

200-600

1000

-40-+80

APC

< 0.2
SC

PC

< 0.2

200-600

1000

-40-+80

APC

< 0.2

ST

< 0.2

200-600

1000

-40-+80

LC

< 0.2

200-600

1000

-40-+80

MU

< 0.2

200-600

1000

-40-+80

MIRJ

< 0.2

200-600

1000

-40-+80

E-2000

< 0.2

200-600

1000

-40-+80

FC-SC

< 0.2

200-600

1000

-40-+80

FC-ST

< 0.3

200-600

1000

-40-+80

SC-ST

< 0.2

200-600

1000

-40-+80

Fiber Optical FC Adaptor

Item

Specification

Item

Specification

Adapter
Singlemdoe(Ceramic Sleeve)

ST (metal body)

Adapter
Multimode(Bronze Sleeve)

ST (metal body)

SC/PC

SC/PC

SC/PC/duplex

SC/PC/duplex

SC/APC

SC/APC

SC/APC/duplex

SC/APC/duplex

FC/PC

FC/PC

FC (D-type metal )

FC (D-type metal )

LC/PC

LC/PC

LC/PC/duplex

LC/PC/duplex

LC/APC

LC/APC

LC/APC/duplex

LC/APC/duplex

DIN/PC/APC

DIN/PC/APC

MTRJ plastic

MTRJ plastic

Hybrid Adaptor
Singlemdoe(Ceramic Sleeve)

FC-SC

Hybrid Adaptor
Multimode(Bronze Sleeve)

FC-SC

FC-ST

FC-ST

SC-ST

SC-ST

DIN-SC

DIN-SC

DIN-ST

DIN-ST

DIN-FC

DIN-FC

Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low RepeatibilityRed Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low RepeatibilityRed Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility

Red Or Yellow Fiber Optic Connector Adapters With Brozen Sleeve Low Repeatibility
