614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units
Specifications
Brand Name :
CTS
Certification :
UN38.3/MSDS/CE
Place of Origin :
Hunan/China
MOQ :
2
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
50000 units per year
Delivery Time :
40 working days
Packaging Details :
Wooden Case
Battery Chemistry :
LiFePO₄ (LFP)
Nominal Voltage :
614.4V
Nominal Capacity :
105Ah/206Ah
Energy :
64.5 kWh/126 kWh
Continuous Discharge Current :
105 A (64.5 kWh) | 206 A (126 kWh)
Charge/Discharge Efficiency :
≥ 98 %
Cooling Method :
Liquid thermal management ‑20 °C ~ 55 °C
Enclosure :
IP67
Application :
GSE, GPU
Cycle life :
>3000 Times DOD80%
OEM/ODM :
Available
Warranty :
2 Years
Description

614.4V 105Ah 206Ah LiFePO4 Aviation GPU Battery 65 kWh 120 kWh Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units CCS2 Fast Charge



Power every turnaround—reliably, cleanly, silently.


Built for GPU carts, this LFP pack delivers instant, emissions-free power to parked aircraft while cutting ground-support fuel costs by up to 90 %.


614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units

Technical Specifications

Item 105 Ah Module 206 Ah Module
Battery Chemistry LiFePO₄ (LFP) LiFePO₄ (LFP)
Nominal Voltage 614.4 V 614.4 V
Energy 64.5 kWh 126 kWh
Continuous Discharge Current 105 A 206 A
Peak Discharge (30 s) 300 A 600 A
Continuous Charge Current 105 A 206 A
Charging Options 20 kW on-board + CCS2 DC 20 kW on-board + CCS2 DC
Charge/Discharge Efficiency ≥ 98 % ≥ 98 %
Cooling / Heating Liquid thermal management Liquid thermal management
IP Rating IP67 IP67
Operating Temperature –20 °C to +55 °C –20 °C to +55 °C
Self-Discharge Rate ≤ 4 % per month ≤ 4 % per month
Dimensions (L × W × H) 1 200 × 650 × 650 mm 1 200 × 1 350 × 650 mm
Weight ≤ 500 kg ≤ 1 000 kg


Why Ground-Handlers Choose This Pack

  • Instant ROI – eliminate idling diesel GPU fuel, cut CO₂ by 30 t yr⁻¹ per unit
  • Whisper-quiet ops – 65 dB @ 1 m, night-curfew friendly
  • Plug-and-play – drop-in replacement for diesel GPU, uses existing 400 V 32 A hangar outlet
  • Remote BMS – GSM/Wi-Fi telemetry, SOC & SOH on your tablet
  • Certified airside – UN38.3, IEC62619, CE, RoHS, IP67, fire-block tested to UL2580

614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units

Why Choose Us?

  • Custom Solutions: Tailor your battery setup based on your GPU's specific needs.
  • Reliable Support: Our experienced team offers expert guidance to ensure you get the best product for your operations.
  • Quality Assurance: All our batteries go through rigorous quality checks to guarantee optimal performance.

614.4V LiFePO4 Aviation GPU Battery Liquid Cooled IP67 Energy Storage Pack for Airport Ground Power Units


Applications:

  • Airport Ground Support Equipment (GSE)
  • Aircraft Towing and Maintenance
  • Hangar Operations
