Specifications
Brand Name :
CTS
Model Number :
CTS-51314-1
Certification :
DNV
Place of Origin :
Hunan, China
MOQ :
2
Price :
2665~5699USD/unit
Payment Terms :
T/T, Paypal, Western Union
Supply Ability :
5000 units/month
Delivery Time :
40 days
Packaging Details :
Wooden boxs
Voltage :
51.2V(Support serial connection)
Capacity :
280Ah 314Ah(Expandable)
Cell type :
A grade LiFePO4 Cell
Advantages :
Long cyclelife, high efficiency and safety
Discharge Rate :
1C~3C
PDU :
External PDU
Size :
L870mm X W50mm X H25mm
Water proof :
≥IP67
Communication :
CAN, RS485,
Cell Grade :
A+ grade
Software :
CTS free software
Application :
Marine, Boat, Craft, Motorboat, etc
Housing material :
304/306 stainless stell housing
Thermal management :
Cooling and heating function for option
OEM/ODM :
Available
Colour :
Black(customizeable)
Cycle times :
Over 4500 cycles
Description

CTS IP67 51.2V 96V 144V 314Ah 628Ah 30kWh 45kWh 60kWh 90kWh Aluminum Housing LFP Lithium Ion Batteries for Marine Boat

╣PRODUCT DESCRIPTION
CTS 51.2V 280/314Ah Marine Lithium Battery Standard Module:
✅Built with LFP cells for HIGH SAFETY and LONG CYCLE LIFE..
✅Supports both series and parallel connection for capacity or voltage expansion, meeting various marine power and endurance requirements.
✅Flexible series and parallel connection.
✅Modular design ensures easy installation, maintenance, and system integration, ideal for yachts, fishing boats, passenger vessels, etc.
CTS IP67 51.2V 96V 144V 314Ah 628Ah 30kWh 45kWh 60kWh 90kWh Aluminum Housing LFP Lithium Ion Batteries for Marine Boat
MODEL
CTS51280
ELECTRICAL SPECIFICATIONS
Cell Type - Chemistry
A grade prismatic lifepo4 cell - 280Ah, 1P16S
Rated Capacity
280Ah/314Ah
Rated Voltage
51.2V
Energy
14.33kWh
Dimensions (L x W x H)
L870*W500*H242mm
Weight
About 120Kg
Housing Material
Lower case aluminum alloy, upper cover stainless steel
Enclosure Protection
IP67
DISCHARGE/CHARGE SPECIFICATIONS
Discharge Cut-off Voltage
40V
Max Continuous Discharging Current(@25℃)
280A/314A max
Peak Discharge Current(@25℃)
750A for 15 seconds
Charging Limited Voltage
58.4V
Max Charging Current(@25℃)
150A(0.5C)
Recommend Charge Current (@25℃)
Less than 140A
TEMPERATURE SPECIFICATIONS
Charge Temperature Range
0~45℃
Discharge Temperature Range
-20~55℃
Recommended Operating Temperature
15~35℃
Storage Temperature & Humidity Range
(Less than 1 month)
-20~35℃, 45~75%RH
Storage Temperature & Humidity Range
(Less than 1 month)
-10~35℃, 45~75%RH
Recommended Storage Temperature & Humidity Range
15~35℃, 45~75%RH
Other
Cooling Method
Build in PI heating film, Build in liquid cooling plate
CTS IP67 51.2V 96V 144V 314Ah 628Ah 30kWh 45kWh 60kWh 90kWh Aluminum Housing LFP Lithium Ion Batteries for Marine Boat
╣PRODUCT ADVANTAGES
✅ Grade-A LiFePO4 cells, with ≥6000 cycles lifespan, ensuring exceptional stability.
✅ Designed for marine applications, undergoing DNV certification, equipped with explosion-proof valve, heating input/output, and cooling support for harsh sea conditions.
✅ Standard module with PDU for controlling dual battery packs, supporting CCS1/CCS2 charging standards.
✅High-precision BMS for real-time voltage, current, and temperature monitoring, preventing overcharge,over-discharge, and thermal runaway.
✅ Comes with cables, charging socket, and other accessories for ready-to-use installation.
CTS IP67 51.2V 96V 144V 314Ah 628Ah 30kWh 45kWh 60kWh 90kWh Aluminum Housing LFP Lithium Ion Batteries for Marine Boat
╣APPLICATIONS
CTS lithium battery Ideal for yachts, fishing boats, passenger vessels, workboats, and research ships for both propulsion and energy storage systems.
✅Series: Increase system voltage for high-power marine applications
✅Parallel: Increase total capacity for extended cruising range
✅Hybrid expansion supported for versatile marine system design
CTS IP67 51.2V 96V 144V 314Ah 628Ah 30kWh 45kWh 60kWh 90kWh Aluminum Housing LFP Lithium Ion Batteries for Marine Boat
╣WHY CHOOSE US ?
* Professional 30+ senior engineers offer 24 hours online service and response within 30 min.
* 10000m² factories, 200 workers, 30 engineers and 4 production lines, 1GWH annual production capacity.
* One-stop customized service for 12V to 1000V battery system.
* 100% OQC testing with 25 detection contents.
* 14 years lithium battery designing and production experience.
* IATF16949 certified factory which ensure quality of products.
* One-Stop battery solution.
* Global on-site technical support.
