Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
Specifications
Model Number :
76
Certification :
CE,BV, ISO
Place of Origin :
China
MOQ :
1 set
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T
Supply Ability :
25 sets per year
Delivery Time :
90 days
Packaging Details :
Plastic film winding, wooden case for electronic components
Product :
Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel
keyword :
tube mill
Material :
Carbon steel
speed :
30-120 m/min
thickness :
1-4 mm
Motor :
400 KW
Application :
application architecture
Certificate :
CE
Features :
FFX
keywords :
Tube Mill Welded Pipe Making
Description

tube mill welded pipe making machine application architecture good quality steel

2 Main Technical Specifications:

2.1 Main Specifications:

2.1.1 Pipe Diameter: Φ27 ～ 76mm( 3/4" ～ 2-1/2" )

2.1.2 Wall Thickness: 1.0～4.0mm

2.1.3 Pipe Length: 4 ～ 8mm

2.1.4 To-length Accuracy: 0 ～ 6mm ( STD )

2.2 Raw Material Conditions:Low carbon steel and low alloy constructional steel

2.2.1 Width of Strip: 100～ 280mm

2.2.2 Thickness of strip: 1.0～4.0mm

2.2.3 Inner Diameter of Coil: 520 ～ 650mm

2.2.4 Outer Diameter of Coil: 900 ～ 1800mm

2.2.5 Weigh of Coil: ≤3t

2.3 Forming Speed: 20 ～ 70m/min

2.4 Total Power: Approve 800KW

2.5 Compressed Air:

2.5.1 Flow Rate: 3m3/min

2.5.2 Pressure: 0.4 ～ 0.7MPa

2.6 Water Supply:

2.6.1 Circulation: 60t/h

2.6.2 Pressure: 0.1 ～ 0.25MPa

Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min

Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min

Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min

Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min

Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min

Carbon Steel Tube Mill Welded Pipe Machine 30-120 m/min
