10-50mm Steel Pipes CNC Automatic Pipe Mill Machine
10-50mm Steel Pipes CNC Automatic Pipe Mill Machine
Specifications
Brand Name :
Tengtian
Model Number :
HG50
Certification :
CE ISO
Place of Origin :
HEBEI,CHINA
MOQ :
1 set
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100 set per year
Delivery Time :
2.5 months
Packaging Details :
packed in seaworthy material
Product Name :
10-50mm Steel Pipes CNC Automatic Pipe Mill Machine
pipe diameter :
10-50mm
product speed :
Max 90m/min
material :
steel pipe,stainless pipe
special require :
can design according to the customer
color :
blue
Keyword :
pipe mill machine
Description
10-50mm Steel Pipes CNC Automatic Pipe Mill Machine
Attribute Value
Product Name CNC Automatic Pipe Mill Machine for Structural Round Pipe
Pipe Diameter 10-50mm
Product Speed Max 90m/min
Material Steel pipe, Stainless pipe
Special Requirement Can be designed according to customer specifications
Color Blue
Why Choose Our Pipe Mill Machine?
  • Professional manufacturer with 12 years experience in metal pipe cutting machines
  • Our intelligent cutting machines offer superior precision and labor-saving operation
  • Innovative research and development for continuous product improvement
Key Features
  • Low-speed rotation high-speed hacksaw for clean cuts with no burrs or deformation
  • Servo feeding with 0.20mm accuracy and customizable feed length up to 1 meter
  • PLC control with easy operation via touch screen interface
  • Programmable for multiple cutting lengths and batch quantities
  • Automatic material detection with shutdown and alarm systems
  • Advanced cooling system extends saw blade durability
  • Lifting function minimizes pipe and mold friction
  • Fast cycle time of 6-7 seconds per piece (adjustable based on pipe size)
  • Vertical chute cutting ensures stability during operation
  • Automatic leftover material removal eliminates secondary processing
  • 10-inch high-resolution LCD with real-time 3D cutting animation
Cold Cutting Saw Specifications
Steel Pipe Material Q235
Diameter Range Round Ø48-Ø152mm, Square 120x120mm
Thickness 4-5mm
Production Line Speed 50-70m/min
Cutting Length 4000-10000mm
Cutting Accuracy ≤±3mm
End Burrs ≤0.2mm
10-50mm Steel Pipes CNC Automatic Pipe Mill Machine
Company Advantages
  • 20 years of manufacturing experience ensuring reliable quality
  • BV certified with onsite inspection
  • Nationally certified for high credibility
  • Independent import/export authority
  • Short delivery times guaranteed
View BV Certificate Details
Model Specifications
Model Diameter Range Thickness Range Max. Speed Motor Saw Blade Dia. Clamping Type
CS - 32 12~38 0.4~2.0 120 YASKAWA / SIEMEMS 350 Pneumatic
CS - 50 20~63.5 0.6~2.0 100 YASKAWA / SIEMEMS 400 Pneumatic/Hydraulic
CS - 60 25~76 0.8~3.0 80 YASKAWA / SIEMEMS 450 Pneumatic/Hydraulic
CS - 76 25~76 0.8~4.0 80 YASKAWA / SIEMEMS 450 Hydraulic
CS - 114 50~114 1.2~5.0 60 YASKAWA / SIEMEMS 600 Hydraulic
Note: The data in the table serves as general reference. We design and manufacture each production line according to specific customer requirements.

10-50mm Steel Pipes CNC Automatic Pipe Mill Machine

10-50mm Steel Pipes CNC Automatic Pipe Mill Machine

10-50mm Steel Pipes CNC Automatic Pipe Mill Machine

10-50mm Steel Pipes CNC Automatic Pipe Mill Machine

1.) We will send the engineer for the installation and training your workers how to operate this machine in correct way.

2.) Warranty Team

One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.

3.) We supply the pre-sell and after-sell service.

pre-sell service: workshop design, and production output design

after-sell service: installation and training, and the skilled engineer for working.

4.) We can also sent the engineer working for you serval months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.

5.) We supply the pre-sell service-Design for whole project for stainless steel pipe making/ carbon steel pipe making.

6.) We will be responsible for the loading and shipping

10-50mm Steel Pipes CNC Automatic Pipe Mill Machine

Our Services
  1. Onsite installation and operator training by our engineers
  2. One year quality guarantee with lifetime repair service
  3. Comprehensive pre-sales and after-sales support
  4. Option for extended engineer support (several months to 1 year)
  5. Complete project design for stainless/carbon steel pipe production
  6. Responsible for loading and shipping arrangements
