MachineU > China Products > Minerals & Metallurgy > Carbon Steel > Steel Pipes > Welded Steel Pipes
Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter
Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter
Specifications
Brand Name :
Tengtian
Model Number :
HG76
Certification :
CE, ISO9001, BV
Place of Origin :
HEBEI,CHINA
MOQ :
1 set
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T,Western Union,
Supply Ability :
50 set per year
Delivery Time :
three months
Packaging Details :
Export waterproof and Seaworthy packing.
product name :
Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter
Pipe Diameter :
25-76mm
product speed :
Max 50m/min
material :
carbon steel,stainless steel,low alloy steel
Cutting Saw :
Friction Saw Cutting
worm gearing :
Max.80m/min
pipe thickness :
4.0-10.0mm
keywords :
Welded Tube Mill Machine
Description
Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter
Product Specifications
Attribute Value
Pipe Diameter 25-76mm
Product Speed Max 50m/min
Material Compatibility Carbon steel, stainless steel, low alloy steel
Cutting Saw Friction Saw Cutting
Worm Gearing Max. 80m/min
Pipe Thickness 4.0-10.0mm
ERW Tube Mill Models
Model Diameter Range Pipe Thickness Line Speed (m/min)
HG20 8-25.4MM 0.3-1.2MM 120
HG32 10-32MM 1.4-1.5MM 120
HG50 16-76MM 0.7-2.5MM 30-120
HG76 25-76MM 1-4MM 30-100
HG89 32-89MM 1-4.5MM 30-80
HG114 45-114MM 1.5-5.0MM 30-60
HG165 60-165MM 3-7MM 30-50
HG219 114-219MM 4-8MM 20-40
HG273 114-273MM 4-10MM 15-30
HG325 165-325MM 4-10MM 10-30
HG426 165-426MM 4-12.7MM 8-25
HG508 219-508MM 4-16MM 8-20

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Our Services
Quality Assurance

We guarantee the quality of our equipment for one year after successful installation and debugging. Any quality problems resulting from design or manufacturing will be our responsibility, including all expenses for replacing parts and components (excluding human factors and vulnerable components).

Installation & Debugging
  • Factory will dispatch 1-2 technical engineers for installation and testing operations
  • Buyer responsibilities include:
    • Preparing the site, equipment foundation, and cooling constructions according to our specifications
    • Providing installation equipment (lifting equipment, tools, etc.)
    • Supplying installation accessory materials (wires, drive pipes, water pipes, etc.)
    • Arranging labor force for installation
  • Buyer must provide power supply, water supply, and gas supply to the equipment interface connector
Buyer Preparation Notes
  • Machinery device location (length × width)
  • Power supply: Main power to equipment control bench, unit position
  • Air feed: Air compressor (1.5 cubic meters/minutes)
  • Water supply: Water source to machine station

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter

Automatic Welded carbon Steel Pipe Production Line 25-76mm Diameter
