HF Automatic Tube Mill for 114.3mm Round Pipe
HF Automatic Tube Mill for 114.3mm Round Pipe
Specifications
Brand Name :
TENG TIAN
Model Number :
HG114
Certification :
ISO9001/BV
Place of Origin :
China
MOQ :
1set
Price :
$100000 to $1 million
Supply Ability :
150 units a year
Delivery Time :
3 months
Packaging Details :
Seaworthy packing
Product Name :
HF Automatic Tube Mill for 114.3mm Round Pipe
Mill Name :
Thickness 3.38mm-6.02mm Round Automatic Tube Mill Dia 114.3mm Include Rollers
Pipe material :
Carbon Steel
After-sales service provided :
On-Site Engineers
Voltage :
380V
Power(w) :
1500KW
Speed :
20 - 60m / min
Pipe Shape :
Round, Square & Rectangular
Round Pipe Diameter :
114.3mm
Warranty :
1 year
Keywords :
Automatic Tube Mill
Key Word :
HF Automatic Tube Mill
Description
HF Automatic Tube Mill for 114.3mm Round Pipe
HF Automatic Tube Mill for 114.3mm Round Pipe
Product Specifications
Attribute Value
Mill Name Thickness 3.38mm-6.02mm Round Automatic Tube Mill Dia 114.3mm Include Rollers
Pipe material Carbon Steel
After-sales service provided On-Site Engineers
Voltage 380V
Power 1500KW
Speed 20 - 60m / min
Pipe Shape Round, Square & Rectangular
Round Pipe Diameter 114.3mm
Warranty 1 year
Product Description
This automatic tube mill is designed to produce welded pipes of 33.4-114.3mm in diameter with wall thickness ranging from 3.38-6.02mm. Featuring an advanced roll pass design, the production line manufactures high-quality welded steel pipes with precision machining and assembly.
The HG114 production line incorporates a double-radius hole design, engineered to enhance operational characteristics, improve safety and production efficiency, while reducing roller costs.
Available Models
Serial No. Model Thickness(mm) Specification(mm) Speed(m/min) Main Engine(kw) Power(kw) Area
1 H20 0.3-1 8-20 30-120 55 60 7*50
2 H32 0.3-2.0 12-32 30-120 75 100 7*50
3 H50 0.8-2.5 16-50 30-110 110 150 7*60
4 H60 0.8-3 20-60 30-100 132 200 7*65
5 H76 1-3 12-76 30-100 320 250 8*80
6 H89 1-4 32-89 30-80 350 300 8*80
7 HG114 1.5-5 45-114 30-60 400 300 10*100
8 HG165 3-7 60-165 30-50 600 400 10*110
9 HG219 4-8 114-219 20-40 800 500 12*150
10 HG273 4-10 114-273 15-30 1000 600 18*160
11 HG325 4-12 165-325 10-30 1200 600 18*180
12 HG426 4-16 165-426 8-25 1400 800 18*180
13 HG508 4-20 219-508 8-20 2000 1000 21*180
Production Process
  • Scroll up
  • Uncoil
  • Flattening
  • End Shear & Butt Welding
  • Accumulator
  • Forming
  • High-frequency induction welding
  • Removing external burr
  • Cooling
  • Sizing
  • Cutting
  • Checking & Collecting
  • Accessing Warehouse

HF Automatic Tube Mill for 114.3mm Round Pipe
Our Service
  • On-site installation and operator training by our engineers
  • One year quality guarantee with lifetime repair service
  • Comprehensive pre-sales and after-sales support including workshop design and production output planning
  • Option for extended engineer support (several months to 1 year) to optimize output and reduce costs
  • Complete project design services for stainless steel and carbon steel pipe production
  • Responsible for loading and shipping arrangements
  • HF Automatic Tube Mill for 114.3mm Round Pipe
HF Automatic Tube Mill for 114.3mm Round Pipe

HF Automatic Tube Mill for 114.3mm Round Pipe

HF Automatic Tube Mill for 114.3mm Round Pipe

HF Automatic Tube Mill for 114.3mm Round Pipe

FAQ :

Q1: Are you manufacturer or trading company?
A1: we are manufactuer , more than 20 years experience.

Q2: What is the max size of pipe you have even produce?
A2: Max φ630mm

Q3:Can I visit your customer machine line?
A3: Yes, but I need to get agreement from my customer firslty.

Q4: what is your machine advantages?
A4:Contain Full automatic, Direct forming square, Share rollers. Fast change system

Q5:How I can get the quotation?
A5:Please send your requires of pipe size , thickness to us.
