1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed
1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed
1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed
1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed
1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed
1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed
Specifications
Brand Name :
Hebei Tengtian
Model Number :
1600*(0.8-5)mm
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C,,T/T
Supply Ability :
1
Delivery Time :
1 month
Packaging Details :
container
Price :
$100000 to $1 million
material :
steel
Max Width :
1600mm
thickness range :
0.8-5mm
Cutting currency :
±0.1mm
Cutting Speed :
0-45m/min
The loading`bearing capacity of the decoiler :
20T
Cutter motor :
75kw
Coiler motor :
90kw
Description

ZJ1600 x 5.0mm sitting line specification

I. Equipment specification: ( 0.8-5mm) *1600mm

Il. Process flow:

Loading coil - decoil -Press and lead steel strip - Simply calibrclip steel strip-guide-slit-Collect the edges - Pre-separation - Press the strip- Separate the steelstrip-Coil-Pack

1Il. Main technical parameters:

1. Material of the strip:

Ordinary carbon steel strip: 0.8-5mm

2.Strip thickness: 0.8-5mm

3. Strip width: 1600mm

4. Cutting accuracy: ±0.1mm

5. Cutting speed: 0- 45m/min

6. The load-bearing capacity of the decoiler: 20T

7. Inner diameter of coil: 500mm

8. Outer diameter of coil: 1800mm

9. Motor:

Cutter: 75KW

Coiler: 90KW

10. The power supply: 380V,50Hz,Three-phase electricity

ther Model Of Slitting Line

Model
(mm)		 Plate thickness
(mm)		 Plate width
(mm)		 Steel coil weight (T) Finished width (mm) Shear article number Shear speed(m/min)
3×500 0.4-3 100-500 7 ≥30 ≤6 140
3×600 0.4-3 100-600 8 ≥30 ≤6 140
3×800 0.5-3 200-800 10 ≥30 ≤8 140
3×1250 0.5-3 400-1250 15 ≥30 ≤10 120
3×1500 0.5-3 600-1500 20 ≥30 ≤12 120
3×1800 0.5-3 900-1600 30 ≥40 ≤13 120
4×1600 0.5-4 900-1600 30 ≥60 ≤13 120
6×1600 1-6 900-1600 30 ≥60 ≤10 110
8×2000 2-8 900-2000 35 ≥70 ≤6 100
10×2200 3-10 900-2200 35 ≥80 ≤5 80
12×2200 3-12 900-2200 35 ≥100 ≤5 50
16×2500 4-16 900-2500 35 ≥100 ≤5 40
20×2500 6-20 900-2500 35 ≥100 ≤4 40

1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed1600mm Steel Slitting Machine for 0.8-5mm Thickness with 45m/min Speed
