Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed
Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed
Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed
Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed
Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed
Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed
Specifications
Brand Name :
TENGTIAN
Model Number :
76
Certification :
ISO9001.BV,CE
Place of Origin :
CHINA
MOQ :
1SET
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
5 Sets/Year
Delivery Time :
60 work days
Packaging Details :
Export waterproof and Seaworthy packing.
Production Name :
Construction Milling Saw 19mm-76mm Pipe Making Machine Automatic Tube Mill
Application :
Tube Production
Voltage :
380V/220V
Pipe diameter :
19-76mm
Thickness :
0.8-3.0mm
Speed :
30-120m/min
key words :
Pipes Making Process Steel Line
Description

Construction Milling Saw 19mm-76mm Pipe Making Machine Automatic Tube Mill

Construction Milling Saw Automatic Round Tube Mill Pipes Making Process Steel Line General Introduction:

Construction Milling Saw 19mm-76mm Pipe Making Machine Automatic Tube Mill is specially used for producingΦ19.05-Φ76.2mm, δ0.8-3.0mm high-frequency straight seam welded pipe and corresponding square pipe and special-shaped pipe(δ≤2.5mm). The composition of equipment is from uncoiler to fixed length cutting saw. Rolling speed can be adjusted correspondingly within suitable range of pipe diameter and wall thickness.

Automatic Round Tube Mill Dimension range of processing steel tube:

(1) O.D.: Φ19.05-Φ76.2mm

(2) Square pipe size: 18x18~60x60mm

(3) rectangle pipe size:15x20~40x80mm

(4) Wall thickness: 0.8-3.0mm(square pipe and special-shaped pipeδ≤2.5mm)

(5) Length: 4-8m

Milling speed: 30-80M/min

Automatic Round Tube Mill Product Process Flow:

raw material (steel coil) → uncoiling → shearing and end welding → material accumulating → non-power leveling → mill-forming → high-frequency welding → removing burrs outside of weld seam → cooling → sizing → roughly straightening → fixed length cutting → finishing tube

Tube Mill Other Model:

Model Diameter Range Pipe Thickness Line Speed(m/min)
HG20 8-25.4MM 0.3-1.2MM 120
HG32 10-32MM 1.4-1.5MM 120
HG50 16-76MM 0.7-2.5MM 30-120
HG76 25-76MM 1-4MM 30-100
HG89 32-89MM 1-4.5MM 30-80
HG114 45-114MM 1.5-5.0MM 30-60
HG165 60-165MM 3-7MM 30-50
HG219 114-219MM 4-8MM 20-40
HG273 114-273MM 4-10MM 15-30
HG325 165-325MM 4-10MM 10-30
HG426 165-426MM 4-12.7MM 8-25
HG508 219-508MM 4-16MM

8-20

Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed

Automatic Tube Mill for 19-76mm Pipes with 30-120m/min Speed
