Straight Seam Welded Steel Square Tube Mill 0.8-4mm Thickness
Straight Seam Welded Steel Square Tube Mill 0.8-4mm Thickness
Straight Seam Welded Steel Square Tube Mill 0.8-4mm Thickness
Straight Seam Welded Steel Square Tube Mill 0.8-4mm Thickness
Specifications
Brand Name :
Tengtian
Model Number :
HG178
Certification :
CE, ISO9001, BV
Place of Origin :
Hebei，China
MOQ :
1 Set
Price :
$100000 to $1 million
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
40 Sets/Year
Delivery Time :
120 work days
Packaging Details :
Export waterproof and Seaworthy packing.
Mill Name :
Straight Seam Welded 0.8mm 50m/Min Steel Square Tube Mill
Mechanical properties :
δs≤500Mpa δb≤345Mpa
Strip Width :
160-560mm
Strip Thickness :
0.8-4.0mm
Round pipe thickness :
0.8-4mm
Pipe Diameter :
50-178mm
Forming Speed :
20-50m/min
Material :
low alloy ，carbon steel
Description

Straight Seam Welded 0.8mm 50m/Min Steel Square Tube Mill

Main Parameters and Specifications:

(1)Material Specifications:
Standard Conforming to the YB189-64 standard
Material Low carbon steel and low alloy constructional steel
Mechanical properties δs≤500Mpa δb≤345Mpa
Strip Width 160-560mm
Strip Thickness: 0.8-4.0mm
Inner Diameter of Coils φ460～φ520mm
Outer Diameter of Coils φ1800mm
Coil Weight ≤8T
(2)Pipe Specification
Pipe Diameter

Round pipe:50-178mm

Square Pipe:40*40-140*140mm

Thickness:0.8-4mm
Length 4-9m
Pipe-cutting Precision 0-6mm
Forming Speed 20-50m/min
(3)The buyer should self-supply
Work shop 100x8m, H＞5m(crane to ground)
Power Approx.800KW 380V/50Hz/3phases
Circulation Cooling Water(whole system)

Flow:30T/h～40 T/h

Pool Volume:60m3
Compressed Air Flow:5m3/min 5-7kg/cm2
Others Seller will supply list
