HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
Specifications
Brand Name :
TENGTIAN
Model Number :
HG89
Certification :
CE ISO9000 BV
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
5 set/month
Delivery Time :
90 wording days
Packaging Details :
standard export package
Price :
$100000 to $1 million
Machine Name :
HG89 Roll Forming Tube Mill Machine For Making Carbon Steel Tube
Product :
round pipe
Feature :
precision
material :
carbon steel and galvanized steel
Other pipe :
square pipe
Max size :
89mm
Thickness :
3mm
Length :
3-6m
Rollers :
not include
Model :
89
Key words :
HG89 Roll Forming Tube Mill Machine For Making Carbon Steel Tube
Description

HG89 Roll Forming Tube Mill Machine For Making Carbon Steel Tube

Tube Mill Machine General Introduction

HG89 Automatic tube mill is designed to produce square pipe 32-89mm and according size square pipe , thickness 1-3mm. Adopting roll pass design, the production line can manufacture welded steel pipes with good quality machining and high precision assembling.

According to the designing guideline of improving the operating character & environment and the safety & producing character , reducing the cost of the roller to guarantee high efficiency,HG89 production line adopts the double-radius hole style of design .


Automatic tube mill Main Parameters and Specifications

(1)Material Specifications:

Standard

Internatioanl standard tube mill machine

Material

galvanized steel

Mechanical properties

σb≤520Mpa,σs≤365MPa

Strip Width

100-280mm

Strip Thickness:

1-3mm

Inner Diameter of Coils

Φ508mm

Outer Diameter of Coils

Φ1300～φ2000mm

Coil Weight

≤2T

(2)Pipe Specification

Pipe Diameter

round pipe :32-76mm

Length

3-6m

Pipe-cutting Precision

0-6mm

Forming Speed

max 90m/min for 2 mm thickness

(3)The buyer should self-supply

Work shop

60x12m, H＞5m(crane to ground)

Power

Approx.3500KW 380V/60Hz/3phases

Circulation Cooling Water(whole system)

Flow:30+30 CBM
Pool Volume:40m3

Compressed Air
(whole system)

Flow:5m3/min
Pressure: 5-7kg/ cm2

Cable

All cable outside of my machine, you buy after machine fix location.

Tube Mill Machine Working Process

HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick

strip steel to coil→uncoiler →end straightener→flattener→shear welder→storage material unit →formed,welding,cooling,accurate pipe Dia. size →accurate pipe length size,cutting→inspection →package

Tube Mill Machine

HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick

HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick

Our Factory for Tube Mill Machine

HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
Our Office
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
Our Team
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
Past Project for Tube Mill Machine
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
Tube Mill Machine and Management Certificate
HG89 Carbon Steel Tube Mill Machine for 32-89mm Pipes 3mm Thick
