High Speed 120m/min Carbon Steel Coil Slitting Machine 0.5-4.0mm
High Speed 120m/min Carbon Steel Coil Slitting Machine 0.5-4.0mm
Specifications
Brand Name :
Tengtian
Model Number :
SJ1600*4
Certification :
CE ISO
Place of Origin :
HEBEI,CHINA
MOQ :
1 set
Payment Terms :
Western Union,L/C,T/T
Supply Ability :
100 set per year
Delivery Time :
two months
Packaging Details :
packed in seaworthy material
Price :
$100000 to $1 million
Name :
High Speed Max 120m / min Carbon Steel Coil Slitting Machine
steel thickness :
0.5-4.0mm
special require :
can design according to the customer
type :
Carbon Steel Slitting Machine
Description

High Speed Max 120m / min Carbon Steel Coil Slitting Machine

I. Steel coil slitting machine General introduction

Steel coil slitting machine is used to uncoil and level the coil plate, slit the steel plate by rotary shearing unit, then recoil the plate by recoiler, at last pack the coil.

1) Coil material: cold/ hot rolled steel

2) Coil thickness: 0.6~3.0mm;

3) Coil width:500~1212mm

4) Coil ID: Φ508~Φ760mm

5) Coil OD: Φ1000~Φ1600 mm

6) Coil maximum weight:18MT

2. Steel coil slitting machine Technical process

Loading coil — uncoiler — straightening head & pinching & leveling machine — hydraulic shearing machine — vertical roll— rotary slitting machine — scrap winder — accumulator — tension device — recoiling machine — discharging car

Remark:

All the above workers should take part in installing the slitting line during installation and debugging, because our engineer could train them about that how to operate and know their machine while installing.

3. Steel coil slitting machine Power supply needed:

Motors of the line without optional machines: 260KW

6. Installation for the user’s reference.

(Plant size details please see Layout drawing):

1) Estimated area needed for the machines:21M×9.5M(L×W)

2) Line foundation drawing will be provided by manufacturer, and the user should build the available foundation according the drawing.

3) 20 tons capacity lifters /1 unit

4) Power supply needed:

Motors of the line: 260KW

3. Steel coil slitting machine DETAILED MACHINES PHOTOS

High Speed 120m/min Carbon Steel Coil Slitting Machine 0.5-4.0mm
