Automatic High Precision Steel Slitting Machine 0.5-4.0mm
Automatic High Precision Steel Slitting Machine 0.5-4.0mm
Automatic High Precision Steel Slitting Machine 0.5-4.0mm
Automatic High Precision Steel Slitting Machine 0.5-4.0mm
Specifications
Brand Name :
Tengtian
Model Number :
SJ1600*4
Certification :
CE ISO
Place of Origin :
HEBEI,CHINA
MOQ :
1 set
Payment Terms :
Western Union,L/C,T/T
Supply Ability :
100 set per year
Delivery Time :
two months
Packaging Details :
packed in seaworthy material
Price :
$100000 to $1 million
material :
carbon steel,stainless steel
product speed :
Max 120m/min
steel thickness :
0.5-4.0mm
special require :
can design according to the customer
type :
Carbon Steel Slitting Machine
Description

Automatic High Precision Steel Coil Slitting Line Machine

Application:It is suitable for the longitudinal shearing of the metal coils and rewinding coils.
Advantages:Easy to operate, slitting quality is high, excellent material utilization, Stepless shearing speed regulation, etc.
Structure:It consist of uncoiler, feeding and positioning, slitting unit, recoiler, etc.
Applicable Materials:Tinplate, silicon steel, aluminum, copper, stainless steel and galvanized steel, etc.

Slitting machine line schematic diagram for your information.

Main Parameters
Processing Thickness
0.3~4mm
Processing Width
1350mm
Slitting Accuracy
±0.15 mm
Slitting Speed
120m/min
Coil Inner Diameter
500/610 mm
Coil Outer Diameter
≤2000 mm
Max. Slitting Numbers
6-22pcs
Slitting Coil Width
≥20 mm
