25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan
Specifications
Brand Name :
MX
Model Number :
MX2507ABH5
Certification :
CE / ROHS
Place of Origin :
China
MOQ :
500pcs
Price :
USD + 2.1 / 2.6 + Piece
Payment Terms :
T / T
Supply Ability :
100000PCS / MONTH
Delivery Time :
10 - 15 DAYS
Packaging Details :
carton box
Size :
25mm X 25mm X 7mm
Bearing :
ball bearing/sleeve bearing
Speed :
6000-12000rpm
Motor type :
DC brushless type
Certifications :
CE ROHS
Material :
Platics frame and impeller
Weight :
5g
Noise :
21-30db
Description

25mm X 25mm X 7mm China Factory Sales Black 5V 12V 10000RPM Micro Dc Axial Fan

Product Description

Frame and Impeller: Plastic (94V-0),PBT
Bearing Type: Sleeve bearing&Ball bearing
Function Range: FG IP58
Leadwire: Red Wire Positive(+),Black Wire Negative(-)
Operating Voltage: 5V 12V
Tempetature Range: –20℃ to +70℃
Motor: Impedance Protected and Reverse Polarity Protected

Model Bearing Type Rated Voltage Operating Voltage Input Current Input Power Speed Max Air Flow Max Static Pressure Noise Weight
Part No. B.S VDC VDC Amp Watt RPM CFM m3/min Inch-H2O pa dB-A g
MX2507AB(S)H5 B.S 5 2.8-6.0 0.18 0.90 12000 1.97 0.06 0.16 39.03 30.00 5.00
MX2507AB(S)M5 B.S 5 2.8-6.0 0.15 0.75 10000 1.57 0.04 0.11 26.48 24.00 5.00
MX2507AB(S)L5 B.S 5 2.8-6.0 0.12 0.60 8000 1.15 0.03 0.07 16.38 21.00 5.00
MX2507AB(S)D5 B.S 5 2.8-6.0 0.07 0.35 6000 0.69 0.02 0.03 7.16 18.00 5.00
MX2507AB(S)H1 B.S 12 7.0-13.8 0.07 0.84 12000 1.97 0.06 0.16 39.03 30.00 5.00
MX2507AB(S)M1 B.S 12 7.0-13.8 0.05 0.60 10000 1.57 0.04 0.11 26.48 24.00 5.00
MX2507AB(S)L1 B.S 12 7.0-13.8 0.04 0.48 8000 1.15 0.03 0.07 16.38 21.00 5.00

25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan

25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan

25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan

Company Information

ShenZhen Topfan China is a professional manufaturer with 11 years experience Which produces AC fan, DC fan, brushless fan, blower fan and EC fan. Our main markets are south Asia,south America, Europe.

“Concentrate on the sevice of customer” is our purpose.

25mm×25mm×7mm 5V 12V 10000RPM Micro DC Axial Fan

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for but not free

Q: How long is your delivery time?

A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
