Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans
Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans
Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans
Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans
Specifications
Brand Name :
MX
Model Number :
MX4015AB ( S ) L2
Certification :
CE / ROHS
Place of Origin :
ShenZhen / GuangDong / China
MOQ :
500 Pieces
Price :
USD + 1 to 5 + Piece
Payment Terms :
T/T, Western Union
Supply Ability :
70000 + Pieces + A Week
Delivery Time :
5 - 8 Working Days
Packaging Details :
Carton Box
Color :
Black
Rated Voltage :
24V
Bearing Type :
Sleeve Bearing & Ball Bearing
START - UP VOLTAGE :
DC 11 . 0V ( ON / OFF )
RATED CURRENT :
0.05A
RATED SPEED :
5500RPM
AIR FLOW :
6 . 5CFM
NOISE LEVEL :
25 . 12dBA
Description

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Rotation Direction :

The blade is count Clockwise viewing from the blade. The same direction also indicated by an arrow mark on one side of the housing

Life Expectancy :

The continuous duty life at given temperature after which 90% of testing units shall still be running

Bearing System

Test Temperature

Test time

Ball Bearing

25℃

50000

Ball Bearing

40℃

45000

Ball Bearing

60℃

38000

Specifications)

***********************************************************************

ITEM SPECIFICATION / CONDITION

BEARING TYPE :Ball Bearing

RATING VOLTAGE : DC 24V

RATED VOLTAGE :DC 15V - 25 . 8V

START-UP VOLTAGE :DC 11.0V ( ON / OFF )

RATED CURRENT :0 . 05A ± 10﹪　

RATED SPEED :5500RPM ± 10%

AIR FLOW :6 . 50CFM

AIR PRESUURE :3 . 18mmH2O

NOISE LEVEL :25 . 12dB ( A )

PROFECFION TRPE

RESISTANCE PROFECTED : YES

AUTO START : NO

TACHOMETER OUTPUT : NO

LOCK ROTOR ALARM OUTPUT : NO

PULSE WIDTH MODULATION : NO

THERMAL SPEED CONTROLLED : NO

CONNECTION LEAD TYPE :UL1007 24 # AWG =250mm RED … POSITIVE , BLACK … NEGATIVE

HOUSING : NO

LABEL :24V - 0 . 05A

  • Voltage:12V , 24V, 48V
  • Insulation Resistance:10M AT 500VDC
  • Dielectric Withstand:Between lead or terminal and housing 700VAC for 3 secretary or 500 VDC for 1Min
  • Opetation Temperature:-10℃～70℃(Ordinary humidity)
  • Storage Temperature:-40℃～70℃(Ordinary humidity)
  • Life Expectancy:Ambient temperature 25℃ and humidity 65%

Ball bearing:50, 000Hours

Sleeve bearing:30, 000Hours

Competitive Advantage:

*Qualified, cost effective and easily operated

*Small in shape, have compact structure

*UL, CE, Rohs, CUL, CCC

* Competitive Pricing

* Keep Investing and Developing In New Products

* The Most Advanced Testing and Measuring Equipment

* On-Time Delivery


Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans

Portable Plastic 40 x 40 x 15mm DC 24V Computer Case Cooling Fans
