Ball Bearing 7 Blade 220V Commercial Ventilation Fans 172x172x51mm
Ball Bearing 7 Blade 220V Commercial Ventilation Fans 172x172x51mm
Ball Bearing 7 Blade 220V Commercial Ventilation Fans 172x172x51mm
Ball Bearing 7 Blade 220V Commercial Ventilation Fans 172x172x51mm
Specifications
Brand Name :
MX
Model Number :
MX17251ABH22
Certification :
CE/ROHS
Place of Origin :
China
MOQ :
500pcs
Price :
US$10 -14
Payment Terms :
T/T, Western Union
Supply Ability :
600,000pcs per month
Delivery Time :
5-12 working days after received your payment
Packaging Details :
carton
Product Name :
AC Cooling Fan
Voltage :
110V / 220V / 380V
Frame :
Aluminum
Impeller :
Plastic
Bearing type :
Ball Bearing/Sleeve bearing
Motor :
Impedance Protected
Size :
172x172x51mm(6.8"x6.8"x2.0")
Description

220V Equipment Cooling Fans / 172x172x51mm AC Ventilation Fans , AC Industrial Fans

220V 172x172x51mm Equipment Cooling Fan, high air flow and long life expectancy , are widely used in network communications, as well as industrial production equipment, medical equipment, home appliances, etc.

Description:

  • 220V AC FAN,used for cooling and ventilation.
  • Frame:Aluminum ADC-12,Painted Black
  • Impeller:Plastic With 7 Blades
  • Stator& Rotor:Silicon steel
  • Magnet Wires:Copper 1 PEW
  • Bobbin:PA-66 UL 94 V-0
  • Bearing Type:Ball Bearing

Specification

Model

MX17251ABH22

Outline Dimension

172x172x51mm

Rated Voltage

AC 220V

Voltage Range

AC 200V~240V

Frequency

50/60Hz

Rated Current

0.26/0.28A±10%

Power Consumption

44/35W±10%

Speed

2500/2200RPM±10%

Max. Air flow

200/187CFM±10%

Max. Static Pressure

0.55/0.50Inch-H2O

Noise Level

53/48dB(A)

Weight

900g

Dielectric Strength

1800V/0.5mA/3s

Temperature Test of Run

t=<70K

Locked Rotor Protection

t=<130K

Environmental Specification

Operating Temperature:-20℃~85℃

Operating Humidity:20%~85%RH

Storage Temperature:-30℃~140℃

Storage Humidity:20%~95%RH
