980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
Specifications
Brand Name :
MX (topfanchina)
Model Number :
MX25489ABH1
Certification :
CE ROHS
Place of Origin :
shenzhen, China
MOQ :
100pcs ( support sample order)
Price :
$ 25.99 - $ 35.99 or Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
40 , 000pcs per month
Delivery Time :
7 - 10 working days after received payment
Packaging Details :
Carton Box or Negotiable
Frame meterial :
Aluminue
Impeller meterial :
Plastic(94v-0), PET
Color :
Black painting
Laber :
Can follow your demands
Bearing type :
Ball bearing
Fan type :
axial fan
Voltage :
12V / 24V
Air volume :
can be customised by your demands
Description

980CFM axial fan 254 x 254 x 89mm, 24V 48V DC waterproof ventilation metal fan for industrial use

Please noted:
1) The size, voltage, power, speed, CFM all can be customised according to the customer, support OEM / ODM.
2) If you want the special functions, like FG RD PWM waterproof, explosion-proof, anti-salt spray, high temperation fan and etc, please contact with us directly.
3) Shenzhen topfan is professional manufacturer of cooling fans for 11 years, we have enough experience to meet your demands.

4) Life warranty: 30000hours for sleeve bearing fans , 50000 hours for ball bearing fans, 30000-50000hours for hydraulic bearing fans.

Basic information:

Material:

Framework: Aluminum Alloy

Impeller: Plastic(94v-0), PET

Protection: Impedance Protected

Temperature Range: -20°C~+70°C

Expected life:

Ball Bearing 50,000 hours(40°C)

Function:

Waterproof ip68, anti-high temperature, dustproof, anti-corrosion and other etc.

Specification:

Model Bearing Type Rated Voltage Operating Voltage Input Current Input Power Speed Max Air Flow Max Static Pressure Noise Weight
Part No. B.S VDC VDC Amp Watt RPM CFM m3/min Inch-H2O pa dB-A g
MX25489ABH2 B 24 14.0-27.6 3.50 84.00 2600 890.00 25.21 1.01 251.58 68.00 2140.00
MX25489ABM2 B 24 14.0-27.6 2.20 52.80 2100 718.85 20.36 0.82 204.25 55.00 2140.00
MX25489ABL2 B 24 14.0-27.6 1.50 36.00 1600 547.69 15.51 0.62 154.44 42.00 2140.00
MX25489ABH4 B 48 28.0-56.0 2.00 96.00 2600 890.00 25.21 1.01 251.58 68.00 2140.00
MX25489ABM4 B 48 28.0-56.0 1.20 57.60 2100 718.85 20.36 0.82 204.25 55.00 2140.00
MX25489ABL4 B 48 28.0-56.0 0.80 38.40 1600 547.69 15.51 0.62 154.44 42.00 2140.00

Fan performance curse:

980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial

Dimension(unit:mm) :

980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial

Company information:

980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial

Shenzhen Topfan Technology Development Co., Ltd. is a professional fan design and processing enterprises. founded in 1996 in Shenzhen China, It's a manufacturer on AC fan and DC brushless fans. Products support OEM, ODM and passed CE RoHS UL EML EMS certificated and good sellers both at home and abroad, the products mainly includs axial fans, cross flow fans (tangential fan), blower fans (centrifugal), being widely used in the information technology, network communications as well as industrial equipment, medical equipment, home appliances and others. 980CFM axial Equipment Cooling Fans 24V 48V DC waterproof ventilation metal fan for industrial
