Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Specifications
Model NO. :
ISO Fuel Tank
Storage Medium :
Moncombustible/Nontoxic
Pressure Level :
Medium Pressure (1.6MPa≤p<10.0MPa)
Condition :
New
Liquid :
Lox, Lco2, Ln2, Food Grade Oil Gas
Transport Package :
Tank Container
Specification :
Customize
Trademark :
WellCare
Origin :
China
HS Code :
7309000000
Production Capacity :
100 Set/Sets Per Month
Description
Product Parameters

Our Tank Contanier Advantages:


Excellent corrosion resistance;
Low permeability of drugs and gases;
Excellent cleaning performance;
The price is moderate;
Excellent and stable welding performance;
It has the characteristics of high purity and no extractables;
Excellent adhesion and stability
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and GasolineUn Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and GasolineUn Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and GasolineUn Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and GasolineUn Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Un Portable T4 ASME Standard Lr Certified 20FT ISO Fuel Tank Container for Diesel and Gasoline
Product Description

Specification

Specifications_20ft ISOTank Container
Tank Type
UN T4 Liquid Tank
Full Frame
Aplicable Medium
General Liquid Chemicals
Vessel Design Code
ASME VIII DIV.1
Approval Standard
IMDG, US DOT CFR 49, RID/ADR, CSC, TC, TIR, UIC, ISO
Main Date
Frame Dimensions
6058 x 2438 x 2591 mm
Capacity
26000 L
Payload
32490 Kgs
Working
Pressure
1.76 Bar (MAX)
Temperature
- 40 to 130 ºC
Details
Vessel
304
Discharge
DN80 (Top) & 3'' BSP(Bottom)
Valves
Safety Relief Valve , Air Inlet Ball Valve
45° Internal Foot Valve integrated a Butterfly Valve
Other
Manhole, Thermometer
Please contact WellCare to get technical specification for final confirmation.
